14 Checklist, Part 2 of 2
We recommend that you print out and work through the checklist for commissioning, replacing the
measuring system and when changing the parameterization of a previously accepted system and
store it as part of the overall system documentation.
Documentation reason Datum edited checked
Sub-item Note Reference yes
– Checklist, part 1 of 2
Document no.:
TR-ECE-BA-GB-0142

This User Manual was read and
understood
–
Document no.:
TR-ECE-BA-GB-0163

Verify that the measuring system
can be used for the present
automation task based on the
specified safety requirements
● Safety functions of the fail-safe
processing unit
● Compliance with all technical
data
● Chapter
Safety functions of the fail-
safe processing unit,
Page 16
● Product data sheets
www.tr-
electronic.com/s/S022978

Supply voltage
● The power supply unit used
must meet the requirements of
● Chapter Supply voltage,
Page 21

Proper
EtherNet/IP
™ installation
● Compliance with valid
international standards or ODVA
guidelines specified for
EtherNet/IP
™
● Chapter
Installation / Preparation for
Commissioning,
from Page 18

Compliance with the safety-
related requirements when using
CIP Safety™ devices according
to ODVA EtherNet/IP™
Specification V2.20, Volume 5,
CIP
™ Safety, Table “TST97 –
Safety Manual Inspection
Requirement”
Applicable to
● Device replacement
● Security connections with
SCID = 0
● SNN No. – Assignment
● SNCT tool configuration –
comparison of SCID and
configuration data
● Validation of all downloads
● Verification of the signature
● Verification of configuration data
● Function test
● Deletion of an existing
configuration
● Programming the TUNID
● Various SIL levels in the network
● Verification of safety connections
● Status EDS
● Automatic SNN assignment
● Locking of configuration data
● Ownership assignment for Type
1 SafetyOpen configurations
● Visual review of configuration
data
● Chapter
Safety-related requirements
when using CIP Safety™
devices
, Page 14
and references

. . .
