Trace Engineering PP-SW2512/D - Page 6

©1999 Trace Engineering
iv
Figure 1
Integrated Power Panel
(layout varies depending upon type of inverter)
PV Charge Controllers (2 each)
AC Circuit Breakers
DC Circuit Breakers
Inverters (2 each)
AC Sub Panel
(to loads)
AC Main Panel
(from utility)
or
Generator
Ø
×
×
Ú
Ú
