13.2 Removable traveller
The removable traveller is fitted with an opening device which is designed in such a way that two deliberate
manual operations are required one after the other for it to be attached to or removed from the wire ropes.
• open the snap hook and remove it from the ring
• release the clip then lift the plate.
13.3 Shock-absorbing sleeves used in limiting the forces in the event of a fall
The forces are limited by shock-absorbing sleeves placed at either end of the wire ropes and at regular intervals
along the wire ropes. At these regular intervals sleeves are placed on both sides of the intermediate anchor.
In the event of a fall, the shock-absorbing sleeves slide along the wire ropes.The distance the shock-absorbing
sleeves located at either end of the wire ropes can slide is limited by the end sleeves. The distance between
these sleeves on assembly is 1 in. (25 mm). After a fall has been stopped this distance is less than 0.8 in. (20
mm).Therefore the position of the shock-absorbing sleeves also gives a visual indication of whether the Travsafe
®
has stopped a fall. If it has stopped a fall a competent person must inspect the system.
14. LABELLING AND PLATES
14.1 Read all labels and plates on the Travsafe
®
system. They must always be intact and easy to read.
fig. 12 fig. 13
fig. 14
