Appendix B - Programming User-defined Satellites
Example - Circular Satellite
The following is an example of programming the fictional
“YOURSAT 122” as the USER2 user-defined satellite.
YOURSAT 122 at 122ºW, DVB decoder, circular polarization
Based on the above information, you would enter the following
commands into the HyperTerminal window:
HALT
SATCONFIG,USER2,122,W,3,C
@DEBUGON
@SATCONFIG,B,99,12225,20000,56,0x1004,R,U,3
@SATCONFIG,B,99,12456,20000,56,0x1004,L,U,3
ZAP
Transponder Data Value
Right
Frequency 12.225 GHz
Symbol rate 20000
FEC code 5/6
Network ID 4100 (dec) = 0x1004
Left
Frequency 12.456 GHz
Symbol rate 20000
FEC code 5/6
Network ID 4100 (dec) = 0x1004
