TracVision M9 User’s Guide
63
Appendix C - Wiring Diagrams
Appendix C
Wiring Diagrams
This appendix provides receiver wiring diagrams for TracVision M9
configurations. Wiring diagrams vary according to system configuration.
For installation instructions, refer to the TracVision M9 Installation Guide.
Contents
Circular Version
Wiring One or Two Receivers .......................................... 65
Wiring Three or Four Receivers....................................... 66
Wiring Up to Eight Receivers ........................................... 67
Linear Quad Version
Wiring Up to Four Receivers ............................................ 67
Wiring Up to Eight Receivers ........................................... 69
Linear Sky Mexico Version
Wiring One or Two Receivers .......................................... 70
Wiring Up to Eight Receivers ........................................... 71
