8
23 Series High Wall Unit
valve cover
Space to the wal l
Space to the ceiling
Space to the wall
Space to the wall
Air outlet side
Space to the floor
or more
or more
6 in. or more
6 in. or more
12 in. or more
20 in. or more
20 in. or more
12 in. or more
or more
.n
i
97
or more
Space to the obstruction
Air outlet side
Space to the wall
Air inlet side
The dimensions of the space necessary for correct
installation of the appliance including the minimum
permissible distances to adjacent structures
6 in.
66
in.
118 in.
Clearance Requirements
NOTE:
The maximum recommended height from the floor to the bottom of the indoor unit is 11.5 ft. (3.5 m).
Refrigeration piping and
high voltage wiring, including
communication and ground
wiring to the multi-zone
outdoor unit.
Note: Refrigeration piping size, length and additional charge is discussed in the Installer's Guide
associated with the outdoor unit.
