Trane Technologies 4TCC4030 - Page 29

18-EB39D1-1A-EN
29
4TCC4042E1
EXTERNAL STATIC PRESSURE (IN.WG) Horizontal Airflow [Cooling Down Airflow]
Motor Speed
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
LOW
Watts
224
[228]
233
[238]
242
[247]
252
[257]
262
[267]
- - - - - -
CFM
1358
[1345]
1393
[1379]
1348
[1334]
1296
[1283]
1253
[1241]
- - - - - -
MED-
LOW
Watts
306
[312]
316
[322]
327
[333]
337
[344]
348
[354]
359
[366]
369
[377]
382
[389]
395
[403]
- -
CFM
1521
[1506]
1490
[1475]
1448
[1433]
1391
[1377]
1362
[1348]
1338
[1325]
1315
[1302]
1307
[1293]
1254
[1241]
- -
MED-
LOW
Watts - - - -
455
[464]
467
[477]
477
[487]
490
[499]
503
[513]
513
[523]
-
CFM - - - -
1529
[1514]
1491
[1476]
1467
[1453]
1425
[1411]
1385
[1371]
1345
[1331]
-
HIGH
Watts - - - -
490
[499]
502
[511]
514
[523]
527
[536]
540
[550]
554
[564]
568
[578]
CFM - - - -
1533
[1518]
1505
[1490]
1476
[1461]
1447
[1433]
1415
[1401]
1383
[1369]
1347
[1334]
Note: Airflow must not exceed 1575 CFM due to condensate blowoff.
4TCC4048E1
EXTERNAL STATIC PRESSURE (IN.WG) Horizontal Airflow [Cooling Down Airflow]
Motor Speed
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
LOW
Watts
302
[308]
313
[320]
324
[330]
332
[339]
346
[352]
- - - - - -
CFM
1583
[1567]
1542
[1526]
1502
[1487]
1460
[1445]
1415
[1401]
- - - - - -
MED-
LOW
Watts
414
[422]
426
[434]
436
[444]
448
[457]
459
[468]
471
[480]
483
[493]
495
[505]
510
[520]
- -
CFM
1763
[1745]
1723
[1706]
1689
[1672]
1648
[1632]
1609
[1593]
1568
[1552]
1527
[1512]
1488
[1473]
1447
[1433]
- -
MED-
HIGH
Watts -
577
[589]
591
[603]
604
[616]
617
[629]
631
[644]
643
[656]
655
[668]
599
[611]
- -
CFM -
1786
[1768]
1757
[1739]
1729
[1712]
1700
[1683]
1675
[1658]
1648
[1632]
1624
[1608]
1504
[1489]
- -
HIGH
Watts - - - - -
613
[625]
631
[644]
643
[656]
647
[660]
611
[623]
-
CFM - - - - -
1769
[1751]
1728
[1711]
1688
[1671]
1652
[1635]
1545
[1530]
-
Note: Airflow must not exceed 1800 CFM due to condensate blowoff.
4TCC4060E1
EXTERNAL STATIC PRESSURE (IN.WG) Horizontal Airflow [Cooling Down Airflow]
Motor Speed
0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
LOW
Watts
515
[524]
523
[533]
533
[545]
544
[558]
- - - - - - -
CFM
1857
[1831]
1831
[1802]
1800
[1765]
1766
[1728]
- - - - - - -
MED-
LOW
Watts
594
[611]
609
[627]
624
[642]
639
[658]
653
[672]
667
[686]
681
[701]
695
[715]
709
[730]
- -
CFM
2031
[2003]
2003
[1975]
1974
[1946]
1940
[1913]
1907
[1880]
1874
[1848]
1837
[1811]
1805
[1780]
1771
[1746]
- -
MED-
HIGH
Watts
749
[770]
759
[781]
769
[790]
779
[804]
788
[819]
803
[832]
816
[845]
830
[858]
845
[872]
860
[887]
-
CFM
2083
[2054]
2058
[2030]
2032
[2010]
2003
[1976]
1974
[1946]
1943
[1911]
1911
[1879]
1877
[1848]
1843
[1817]
1807
[1781]
-
HIGH
Watts
900
[940]
910
[936]
921
[937]
932
[948]
941
[962]
956
[975]
969
[990]
983
[992]
997
[987]
1010
[985]
-
CFM
2201
[2201]
2177
[2151]
2152
[2120]
2127
[2095]
2105
[2066]
2071
[2033]
2041
[1999]
2009
[1937]
1975
[1921]
1940
[1871]
-
Note: Airflow must not exceed 2250 CFM due to condensate blowoff.
