Trane Technologies 4TWV8049A1000B - Refrigeration Circuits; 5 Ton A;C Refrigeration Circuit

4T-V8-SF-1M-EN
39
Figure 19. 5 Ton A/C (060 Models)
FIELD INSTALLED
INTER-CONNECTING
TUBING
INDOOR
SECTION
OUTDOOR
SECTION
REFRIGERANT FLOW
1/4 FLARE
PRESSURE
TAP
SUCTION
LINE
FIELD
CONNECTION
INDOOR
COIL
PRESSURE
TRANSDUCER
HPCO
COMPRESSOR
1/4 FLARE
PRESSURE
TAP
DRIER
FIELD
CONNECTION
LIQUID LINE
DISCHARGE
LINE
DRIVE
COOLING
LOOP
REFRIGERANT FLOW
OUTDOOR
COIL
RReeffrriiggeerraattiioonnCCiirrccuuiittssffoorrHHeeaattiinnggaannddCCoooolliinngg
