Installer’s Guide
Figure 13. Typical Rooftop Down Airow Application with Frame
Figure 12. Typical Rooftop Horizontal Airow Application with Frame
Supply Air
Return Air
Roof Flashing
Channel Iron Center
Support (Center Sup-
port required on all
Frame Applications.)
Angle Iron Frame
Roof Flashing
Return Air
Angle Iron Frame
Roof Flashing
Supply Air
Channel Iron Center Support
(Center Support required on all
Frame Applications.)
