Trane 4TCC4036A1000A - Page 6

6
18-EB30D1-1G-EN
Figure 2. 2 — 3 TON MODELS
Model
Height MM/IN
APPROX. CORNER WEIGHT
KG /
LBS
SHIPPING
WIGHT
KG / LBS
TOTAL
UNIT
WEIGHT
KG / LBS
CENTER OF GRAVITY
MM/IN.
A W1 W2 W3 W4 B C
4TCC4024
898.53 [35 - 3/8]
58.3
[129]
36.8 [81]
26.1
[58]
41.0
[90]
196.1
(432)
162.4
(358)
479.8 [18.9] 527.8 [20.8]
4TCC4030
61.3
[135]
38.7 [85]
27.5
[61]
43.1
[95]
204.8
(451)
171.1
(377)
406.5 [16.0] 594.1 [23.4]
4TCC4036
61.7
[136]
38.9 [86]
27.7
[61]
43.7
[96]
205.7
(453)
172.0
(379)
414.3 [16.3] 697.6 [27.5]
4WCC4024
52.9
[117]
33.3 [73]
24.1
[53]
38.3
[84]
182.3
(402)
148.6
(328)
430 [16.9]
565.3 [22.3]
4WCC4030
55.3
[122]
50.3 [110]
16.6
[37]
39.2
[86]
195.0
(430)
161.3
(355)
413.5 [16.3] 581 [22.9]
4WCC4036
59.6
[131]
37.3 [82
]
26.6
[59]
41.7
[92]
199.0
(439)
165.3
(364)
430 [17.0]
535 [21.1]
949.33 [37-3/8]
898.53 [35-3/8]
949.33 [37-3/8]
SStteepp22——DDeetteerrmmiinneeUUnniittCClleeaarraanncceess
