24
18-GF79D1-1A-EN
1. See Product Data or Air Handler nameplate for approved combinations of Air Handlers and Heaters.
2. Heater model numbers may have additional suffix digits.
Table 7. Electrical Data
5TEM6B02AV21SAA HEATER DATA
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 2.8* 4 15 2.8* 4 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.84 13100 16.0 24 25 2.88 9800 13.8 21 20
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.80 16400 20.0 29 30 3.60 12300 17.3 25 25
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.68 26200 32.0 44 45 5.76 19700 27.7 38 40
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.60 32800 40.0 54 60 7.20 24600 34.6 47 50
BAYHTR1517BRK
Circuit 1
(a)
2/1
9.60 32800 40.0 54 60 7.20 24600 34.6 47 50
BAYHTR1517BRK
Circuit 2
4.80 16400 20.0 25 25 3.60 12300 17.3 22 25
BAYHTR3510LUG
1/3
9.60 32800 23.1 32 35 7.20 24600 20.0 28 30
BAYHTR3517LUG
1/3
14.40 49100 34.6 46 50 10.80 36900 30.0 41 45
* = Motor Amps
(a)
MCA and MOP for circuit 1 contains the motor amps
5TEM6B03AV21SAA HEATER DATA
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 4.3* 5 15 4.3* 5 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.84 13100 16.0 25 25 2.88 9800 13.8 23 25
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.80 16400 20.0 30 30 3.60 12300 17.3 27 30
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.68 26200 32.0 45 45 5.76 19700 27.7 40 40
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.60 32800 40.0 55 60 7.20 24600 34.6 49 50
BAYHTR1517BRK
Circuit 1
(a)
2/1
9.60 32800 40.0 55 60 7.20 24600 34.6 49 50
BAYHTR1517BRK
Circuit 2
4.80 16400 20.0 25 25 3.60 12300 17.3 22 25
BAYHTR3510LUG
1/3
9.60 32800 23.1 34 35 7.20 24600 20.0 30 30
BAYHTR3517LUG
1/3
14.40 49100 34.6 48 50 10.80 36900 30.0 42 45
* = Motor Amps
(a)
MCA and MOP for circuit 1 contains the motor amps
PPeerrffoorrmmaannccee aanndd EElleeccttrriiccaall DDaattaa
