Performance Data
14 SSP-PRC001-EN
15 Tons Gross Cooling Capacities
Table 5. Gross Cooling Capacities (MBh) 15 Tons TWA180B Heat Pump with 15 Tons TWE180B Air Handler
CFM Air
flow
Ent
DB °F
Ambient Temperature
85 95 105
Entering WB
61 67 73 61 67 73 61 67 73
MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
5400 75 167.8 134.1 185.1 112.3 203.6 75.2 161.9 131.2 178.6 109.7 196.4 72.7 155.5 128 171.6 106.9 188.9 70.1
80 168.7 157 185.4 128.9 203.7 99.1 163 154.1 178.9 126.2 196.5 96.4 156.9 151.1 171.8 122.9 189.1 93.7
85 173.3 173.31 185.7 151.5 203.9 122.5 168.4 168.41 179.2 148.6 196.8 119.8 163 163.01 172.3 145.5 189.4 117.1
90 182 182.01 186.8 174.4 204.1 145.5 176.9 176.91 180.6 171.6 197 142.7 171.4 171.41 174 168.7 189.6 139.8
6000 75 170.9 140.3 188.3 109.4 206.8 76.7 164.8 137.3 181.5 106.6 199.3 74.1 158.3 134.2 174.4 103.7 191.6 71.3
80 172.3 165.5 188.4 134.5 206.8 102.3 166.5 162.6 181.7 131.6 199.5 99.7 160.3 159.5 174.7 128.5 191.8 96.9
85 178.8 178.81 188.9 159.2 207.1 127.9 173.6 173.61 182.3 156.3 199.8 125.2 168 168.01 175.3 153.2 192.2 122.5
90 187.9 187.91 190.7 184.5 207.3 152.7 182.5 182.51 184.4 181.7 200 149.9 176.8 176.81 176.9 176.91 192.5 146.9
6600 75 173.5 146.3 190.9 113 209.3 77.8 167.2 143.2 184 110.2 201.7 75.1 160.5 140 176.7 107.3 193.9 72.3
80 175.6 173.7 191.1 139.9 209.4 105.4 169 169.01 184.3 137 201.9 102.7 163.3 163.31 177 133.8 194.1 100
85 183.6 183.61 191.7 166.7 209.8 133 178.1 178.11 184.9 163.7 202.3 130.3 172.3 172.31 177.9 160.6 194.3 127.2
90 192.9 192.91 194.3 194.31 210 159.6 187.3 187.31 187.5 187.51 202.6 156.7 181.4 181.41 181.6 181.61 194.9 153.8
7200 75 175.7 152 193.1 116.5 211.5 78.8 169.4 148.9 186.1 113.7 203.7 76 162.6 145.6 178.6 110.7 195.8 73.3
80 178.2 178.21 193.4 145.1 211.6 108.4 172.7 172.71 186.4 142.1 204 105.7 166.9 166.91 179 139 196.1 102.9
85 187.8 187.81 194.2 173.9 212 138 182.1 182.11 187.4 170.9 204.2 134.8 176.1 176.11 180.2 167.8 196.4 131.8
90 197.4 197.41 197.5 197.51 212.3 166.3 191.6 191.61 191.7 191.71 204.7 163.4 185.4 185.41 185.6 185.61 196.9 160.4
CFM Air
flow
Ent
DB °F
Ambient Temperature
115
Enter WB
61 67 73
MBH SHC MBH SHC MBH SHC
5400 75 148.8 124.7 164.3 104 181.1 67.5
80 150.4 147.9 164.6 119.8 181.4 90.8
85 157.3 157.31 165.1 142.4 181.8 114.3
90 165.7 165.71 167.2 165.6 182 136.8
6000 75 151.3 130.8 166.9 100.7 183.7 68.5
80 153.5 153.51 167.2 125.3 184 94.1
85 162.1 162.11 168 150 184.4 119.7
90 170.8 170.81 171 171.01 184.7 144
6600 75 153.5 136.6 169.1 104.2 185.8 69.5
80 157.3 157.31 169.5 130.6 186.2 97.2
85 166.2 166.21 170.5 157.5 186.4 124.2
90 175.2 175.21 175.4 175.41 187 150.8
7200 75 155.5 142.2 170.9 107.7 187.6 70.4
80 160.7 160.71 171.3 135.7 188 100.1
85 169.8 169.81 172.8 164.6 188.4 128.8
90 179.1 179.11 179.3 179.31 188.9 157.4
Notes:
1. Dry coil condition. Total gross capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All temperatures are in °F.
3. All capacities shown are gross and have not considered indoor fan heat.
4. To obtain net cooling capacities, subtract indoor fan heat.
5. MBH = Total Gross Cooling Capacity
6. SHC = Sensible Heat Capacity
