20 SSP-PRC001-EN
Performance Data
7½, 10 Tons Gross Heating Capacities
Table 11. Gross Heating Capacities (MBh) 7½ Tons TWA090A Heat Pump with 7½ Tons TWE090A Air Handler at 3000 CFM
Outdoor Temp
(°F)
Heating Capacity (BTUH/1000)
at Indicated Indoor Dry Bulb Temperature
Total Power in kW
at Indicated Indoor Dry Bulb Temperature
60 70 75 80 60 70 75 80
-18 35.2 32 30.9 30.1 5.4 5.9 6.2 6.5
-13 36.8 34 33.1 32.5 5.5 6 6.3 6.6
-8 38.7 36.4 35.7 35.2 5.6 6.1 6.4 6.7
-3 41.1 39.2 38.7 38.3 5.7 6.2 6.5 6.8
2 44.1 42.5 42 41.8 5.8 6.3 6.6 6.9
7 47.5 46.3 45.9 45.7 5.9 6.5 6.8 7.1
12 51.3 50.3 50 49.9 6 6.6 6.9 7.2
17 55.6 54.8 54.5 54.3 6.2 6.7 7.1 7.4
22 60.3 59.6 59.3 59.1 6.3 6.9 7.2 7.6
27 65.5 64.7 64.4 64.2 6.4 7 7.4 7.7
32 71 70.2 69.9 69.6 6.6 7.2 7.5 7.9
37 76.7 75.8 75.4 75 6.7 7.4 7.7 8.1
42 82.7 81.7 81.2 80.7 6.9 7.5 7.9 8.3
47 89 87.8 87.3 86.7 7 7.7 8.1 8.5
52 95.7 94.4 93.7 93.1 7.2 7.9 8.3 8.7
57 102.7 101.2 100.5 99.7 7.3 8 8.4 8.9
62 109.9 108.2 107.4 106.6 7.5 8.2 8.6 9.1
67 117.3 115.5 114.6 113.8 7.7 8.4 8.8 9.3
72 124.8 122.9 122 121.1 7.9 8.6 9 9.5
Notes:
1. Rated with 25 feet of 13/8" suction and ½" liquid line.
Table 12. Gross Heating Capacities (MBh) 10 Tons TWA120A Heat Pump with 10 Tons TWE120A Air Handler at 4000 CFM
Outdoor Temp
(°F)
Heating Capacity (BTUH/1000)
at Indicated Indoor Dry Bulb Temperature
Total Power in kW
at Indicated Indoor Dry Bulb Temperature
60 70 75 80 60 70 75 80
-18 29.9 42.3 46.5 49.9 7.4 8.4 9 9.5
-13 39.4 47.5 50.6 53 7.7 8.6 9.1 9.6
-8 46.9 52.6 54.8 56.7 7.9 8.8 9.2 9.7
-3 53.7 57.8 59.4 60.7 8.1 9 9.4 9.9
2 60.3 63.1 64.2 65 8.3 9.1 9.6 10
7 66.9 68.6 69.2 69.7 8.5 9.3 9.7 10.2
12 73.4 74.3 74.6 74.7 8.7 9.5 9.9 10.3
17 80.2 80.3 80.2 80.2 8.9 9.6 10.1 10.5
22 87.1 86.6 86.3 86 9 9.8 10.2 10.7
27 94.2 93.2 92.6 92.2 9.2 10 10.4 10.9
32 101.7 100.2 99.5 98.9 9.4 10.2 10.6 11.1
37 109.1 107.2 106.4 105.6 9.5 10.4 10.9 11.4
42 116.7 114.4 113.5 112.7 9.7 10.6 11.1 11.6
47 124.6 122.1 121.1 120.1 9.9 10.8 11.3 11.9
52 132.8 130.1 129 127.9 10.1 11.1 11.6 12.1
57 141.1 138.3 137.1 136 10.4 11.3 11.9 12.4
62 149.6 146.7 145.3 144.1 10.6 11.6 12.1 12.7
67 158.3 155.2 153.8 152.5 10.9 11.9 12.4 13.1
72 167.4 164.1 162.6 161.2 11.2 12.2 12.8 13.4
Notes:
1. Rated with 25 feet of 1 3/8" suction and ½" liquid line.
