SSP-PRC001-EN 23
Performance Data
Evaporator Fan Performance, Low Static Fan Drive, 7½ Tons
Table 17. Evaporator Fan Performance 7 1/2 Ton TWE090A, TWE090B - Air Handler
External Static Pressure (Inches of Water Gauge)
.10" .20" .30" .40" .50" .60" .70" .80" .90" 1.00"
CFM RPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHP
1.5 HP Standard Motor & Field Supplied
Low Static Drive
(i)
(i)
Field Supplied Low Static Drive (use Table 18)
1.5 HP Standard Motor & Low Static Drive Kit
1.5 HP Standard Motor &
Sheaves
2400 429 0.45 475 0.51 522 0.58 569 0.65 615 0.71 662 0.78 708 0.84 755 0.91 783 0.98 811 1.05
2550 453 0.48 496 0.55 539 0.61 582 0.68 626 0.74 669 0.81 712 0.87 756 0.94 785 1 814 1.08
2700 476 0.52 516 0.58 556 0.65 596 0.71 636 0.77 676 0.83 716 0.9 758 0.96 787 1.02 816 1.11
2850 500 0.55 537 0.62 573 0.68 610 0.74 646 0.8 683 0.86 720 0.92 759 0.99 788 1.05 819 1.14
3000 524 0.59 557 0.65 590 0.71 624 0.77 657 0.83 690 0.89 723 0.95 760 1.01 790 1.07 821 1.17
3150 546 0.62 577 0.68 609 0.75 640 0.81 672 0.87 703 0.94 735 1.00 768 1.07 798 1.15 829 1.25
3300 568 0.65 598 0.72 628 0.79 657 0.85 687 0.92 717 0.99 746 1.05 776 1.12 807 1.22 837 1.33
3450 589 0.67 618 0.75 647 0.83 676 0.91 705 0.99 733 1.07 762 1.15 791 1.23 820 1.33 849 1.42
3600 611 0.69 639 0.79 666 0.88 694 0.97 722 1.06 750 1.16 778 1.25 806 1.34 834 1.43 862 1.51
External Static Pressure (Inches of Water Gauge)
1.10" 1.20" 1.30" 1.40" 1.50" 1.60" 1.70" 1.80"
CFM RPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHP
1.5 HP Standard Motor & Sheaves
2400 840 1.11 868 1.18 896 1.25 924 1.32 952 1.39 890 1.46 1009 1.52 1037 1.59
2550 843 1.15 872 1.23 901 1.31 930 1.38 959 1.46 988 1.54 1016 1.61 1045 1.69
2700 846 1.19 876 1.28 905 1.36 935 1.45 965 1.53 995 1.62 1024 1.7 1054 1.79
2850 849 1.23 880 1.33 910 1.42 941 1.51 971 1.6 1002 1.7 1032 1.79 1063 1.88
3000 853 1.27 884 1.37 915 1.48 946 1.58 978 1.68 1009 1.78 1040 1.88 1071 1.98
3150 860 1.35 891 1.45 922 1.56 958 1.66 984 1.76 1014 1.86 1044 1.94 — —
3300 868 1.43 898 1.54 929 1.64 959 1.74 990 1.85 1020 1.95 1049 2.01 — —
3450 879 1.52 908 1.61 937 1.71 966 1.8 995 1.9 1025 2 ————
3600 890 1.6 918 1.69 945 1.78 973 1.87 1001 1.96 ——————
2 HP Oversized Motor & Sheaves
Notes:
1. Data includes pressure drop due to wet coil and 1" filter.
2. Fan motor heat (MBh) = 3.15 x BHP.
3. Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and
continuously at all cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabular data will not result in nuisance
tripping or premature motor failure. Our product’s warranty will not be affected.
Table 18. Low Static Fan Drive 7½ Tons TWE090A, B Air Handler
Field Supplied Low Static Fan Drive
7½ Tons TWE090A, B Air Handler
(i)
(i)
Field supplied components required:
Blower Sheave: Fixed Pitch (9.8 inch Pitch Diameter), Blower Sheave: 1.00 inch Bore,
Single Groove, "A" Belt. Belt: A55
Low Static Fan Drive Accessory Kit
7½ Tons TWE090A, B Air Handler
Motor Sheave
Turns Open
Nominal
RPM
Motor Sheave
Turns Open
Nominal
RPM
0 598 0 733
1 563 1 690
2 528 2 647
3 493 3 604
4 458 4 561
5 422 5 518
To Next Page
