26 SSP-PRC001-EN
Performance Data
Evaporator Fan Performance, Low Static Fan Drive, 15 Tons
Table 23. Evaporator Fan Performance 15 Tons TWE180B - Air Handler
External Static Pressure (Inches of Water Gauge)
.10" .20" .30" .40" .50" .60" .70" .80" .90" 1.00" 1.20
CFM RPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHPRPMBHP
3 HP Standard Motor and Field Supplied Low Static Drive
(i)
(i)
Field Supplied Low Static Drive (use Table 24)
3 HP Standard Motor and Sheaves
4500 637 1.4 662 1.44 687 1.49 701 1.53 717 1.58 732 1.63 747 1.64 754 1.65 782 1.67 817 1.76 873 1.96
4800 642 1.42 667 1.51 692 1.54 706 1.63 722 1.64 737 1.65 752 1.66 767 1.68 795 1.73 831 1.82 887 2.02
5100 647 1.45 672 1.52 697 1.57 713 1.66 726 1.68 740 1.70 761 1.72 783 1.77 811 1.85 843 1.96 900 2.19
5400 652 1.47 677 1.54 702 1.6 719 1.69 730 1.72 742 1.75 769 1.78 798 1.87 827 1.98 856 2.09 914 2.37
5700 653 1.48 679 1.56 706 1.67 725 1.75 741 1.80 758 1.84 786 1.92 815 2.02 843 2.14 872 2.27 932 2.57
6000 655 1.49 681 1.59 709 1.74 731 1.8 752 1.87 774 1.94 803 2.05 831 2.17 860 2.29 889 2.44 950 2.78
6300 658 1.51 687 1.63 716 1.79 741 1.89 765 1.98 792 2.09 823 2.22 853 2.35 883 2.49 913 2.64 974 2.96
6600 663 1.54 693 1.68 723 1.84 750 1.97 778 2.09 811 2.24 843 2.39 875 2.53 906 2.69 936 2.84 997 3.15
6900 670 1.62 700 1.77 735 1.98 767 2.15 799 2.29 832 2.44 865 2.61 900 2.79 934 2.98 967 3.16 1019 3.48
7200 677 1.7 707 1.86 747 2.12 785 2.33 819 2.49 853 2.65 888 2.83 926 3.05 963 3.27 997 3.49 1041 3.81
5 HP Oversized Motor and Sheaves
External Static Pressure (Inches of Water Gauge)
1.40" 1.60" 1.80" 2.00" 2.20" 2.40"
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor and
Sheaves
5 HP Oversized Motor and Sheaves
4500 929 2.19 986 2.46 1035 2.74 1084 3.01 1132 3.28 - -
4800 943 2.29 999 2.56 1046 2.83 1095 3.11 1143 3.38 - -
5100 957 2.48 1012 2.76 1058 3.04 1105 3.31 1152 3.57 - -
5400 972 2.67 1024 2.96 1070 3.24 1116 3.51 - - - -
5700 990 2.89 1038 3.18 1083 3.46 1127 3.74 - - - -
6000 1008 3.11 1052 3.39 1096 3.68 1138 3.96 - - - -
6300 1025 3.3 1069 3.61 1113 3.92 1152 4.21 - - - -
6600 1042 3.49 1087 3.83 1130 4.16 - - - - - -
6900 1063 3.81 1107 4.15 1146 4.49 - - - - - -
7200 1085 4.14 1127 4.47 - - - - - - - -
Notes:
1. Data includes pressure drop due to wet coil and 2" filter.
2. Fan motor heat (MBh) = 3.15 x BHP.
3. Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably
and continuously at all cataloged conditions. Using the full horsepower range of our fan motors as shown in our tabular data will not result
in nuisance tripping or premature motor failure. Our product’s warranty will not be affected.
Table 24. Low Static Fan Drive 15 Ton TWE180B Air Handler
(i)
(i)
Field supplied components required:
Motor Sheave: Variable Pitch (4.3-5.5 inch Pitch Diameter),
0.875 inch Bore, Single Groove, "B" Belt.
Blower Sheave: Fixed Pitch (12.4 inch Pitch Diameter),
1.4375 inch Bore, Single Groove, "B" Belt.
Belt: B67
Motor Sheave Turns Open Nominal RPM
0 776
1 748
2 720
3 692
4 663
5 635
6 607
