30
18-GF81D1-1A-EN
Figure 17. 5TEM4B02AC21SA/ 5TEM4B03AC31SA/ 5TEM4D04AC31SA/ 5TEM4D05AC41SA
Top Cap
Snap Tab
Feature
Snap Tab
Feature
Top Cap
Replace 2 screws
and water diverter
bracket
Remove 2 screws
and water diverter
bracket
Figure 18. 5TEM6D06AV51SA/ 5TEM6D07AV51SA
Snap Tab
Feature
Top Baffle
Assembly
Remove 2 screws
and water diverter
bracket
Snap Tab
Feature
Top Baffle
Assembly
Replace 2 screws
and water diverter
bracket
UUnniitt CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
