Trane AM4A0A30S21SA Series User Manual

CLCH-SVX07C-EN 11 3
Start-Up
Table 31. Back or top inlet low-flow Traq dampers - air-mixing and indoor economizer sections - VCM voltage versus airflow at sea level
Unit
Size
Part
Number
Traq
Damper
Size (in)
Damper
Type Quantity
Peak Velocity
(fpm)
Total Area
(ft
2
)
CFM @ 10VDC
Peak Velocity
L/s @ 10VDC
Peak Velocity
4 50182901 13
Min. Outside Air 1
2475
0.92 2279 1076
Economizing 1 0.92 2279 1076
6 50182901 13
Min. Outside Air 1
2475
0.92 2279 1076
Economizing 1 0.92 2279 1076
8 50182901 13
Min. Outside Air 1
2475
0.92 2279 1076
Economizing 2 1.84 4554 2149
10 50182901 13
Min. Outside Air 1
2475
0.92 2279 1076
Economizing 2 1.84 4554 2149
12 50182902 16
Min. Outside Air 1
2475
1.40 3455 1630
Economizing 2 2.79 6910 3261
14 50182902 16
Min. Outside Air 1
2475
1.40 3455 1630
Economizing 2 2.79 6910 3261
17 50182902 16
Min. Outside Air 1
2475
1.40 3455 1630
Economizing 2 2.79 6910 3261
21 50182924 20
Min. Outside Air 1
2600
2.18 5671 2676
Economizing 2 4.36 11341 5352
25 50182924 20
Min. Outside Air 1
2600
2.18 5671 2676
Economizing 2 4.36 11341 5352
30 50182903 24
Min. Outside Air 1
2600
3.14 8164 3853
Economizing 2 6.28 16328 7705
35 50182903 24
Min. Outside Air 1
2600
3.14 8164 3853
Economizing 2 6.28 16328 7705
40 50182903 24
Min. Outside Air 1
2600
3.14 8164 3853
Economizing 2 6.28 16328 7705
50 50182904 28
Min. Outside Air 1
2600
4.27 11112 5244
Economizing 2 8.55 22224 10488
57 50182904 28
Min. Outside Air 1
2600
4.27 11112 5244
Economizing 2 8.55 22224 10488
66 50182904 28
Min. Outside Air 1
2600
4.27 11112 5244
Economizing 3 12.82 33336 15731
80 50182904 28
Min. Outside Air 1
2600
4.27 11112 5244
Economizing 4 17.10 44448 20975
100 50182904 28
Min. Outside Air 1
2600
4.27 11112 5244
Economizing 5 8.55 22224 10488
120 50182904 28
Min. Outside Air 1
2600
4.27 11112 5244
Economizing 5 21.37 55561 26219
Trane utilizes AMCA certification for airflow measuring stations. Trane certifies that the Traq damper
herein is licensed to bear the AMCA seal. The ratings shown are based on tests and procedures performed
in accordance with AMCA Publication 611 and comply with the requirements of the AMCA Certified
Ratings Program.
The certification program provides the engineer and owner assurance that manufacturer-published
performance ratings for airflow measurement stations are accurate and repeatable. Trane Traq dampers
are certified with the integral ventilation control module which converts differential pressure to an
electronic signal for control.
Refer to Performance Climate Changer Air Handler catalog CLCH-PRC015-EN for Traq damper testing and
rating information.
