Trane AM4A0A30S21SA Series User Manual

32
STEP 8 - Replace Coil panel making sure that the
wires are located within the wire pass-through pro-
vided in the panel.
STEP 7 - Slide control plate assembly into the control
pocket until fully seated. The control plate should be
flush with the outer edge of the unit.
Pass through
notch in coil
access door

Trane AM4A0A30S21SA Series Specifications

General

Brand	Trane
Model	AM4A0A30S21SA Series
Category	Air Handlers
Language	English
