CLCH-SVX07C-EN 33
Installation - Mechanical
Figure 17. Coil-section-to-downstream-section bolt up with splash guard (shown for sizes 3-30)
Figure 18. Stacked unit assembly (shown for sizes 3-50)
Butyl Tape
0.380 in. T x 0.380 in. W
Gasket
0.375 in. T
x
0.750 in. W
Gasket
1.00 inches T
x
4.00 inches W
