9 ACC-SVN28A-EN
Installation
Table 4.
Option Function Option Value Default Description
1 Morning warm-up 0 = Disabled
1 = Enabled
0 When enabled, Heat is turned on if the Zone temperature is 2 degrees
below the heat set point temperature when the program switches from
unoccupied to occupied. The heat will terminate after 60 minutes regardless
if the set point has been reached.
2 Economizer
minimum position
override
0 = Disabled
1 = Enabled
1 When enabled, the minimum position of the economizer damper is
overridden during the unoccupied period.
3Temperature
Scale
0 = Fahrenheit
1 = Centigrade
0 Displays the temperature in the selected format.
4Supply Air
Tempering
0 = Disabled
1 = Enabled
0 When enabled, sends the tempering signal to the UCP.
5 Time Clock 0 = 12 hour
1 = 24 hour
0 Sets Clock to 12 hour format with AM and PM or 24 hour military time.
6Smart Fan 0 = Disabled
1 = Enabled
1 When enabled, the supply fan operates in the AUTO mode during
unoccupied periods regardless of FAN setting.
7 Intelligent
Temperature
Recovery
0 = Disabled
1 = Enabled
0 When enabled, offsets the set point temperature and starts the system
before the scheduled occupied period to efficiently reach the occupied
temperature set point. The time is calculated based on a recovery rate of 6
degrees per hour. If option 19 is set
8 Programmable
Days/Week
0 = 7 days (M, T, W, T, F,
S, S) 1 = 3 days (M-F, S,
S) 2 = 2 days (M-F, S-S)
3 = 1 day (Sun-Sat)
0 0 allows all 7 days to be individually programmed. 1 allows Mon - Fri, Sat &
Sun to be programmed separately. 2 allows Mon - Fri and Sat - Sun to be
programmed the same. 3 uses the same program for each day of the week.
9 Programmable
Periods/Day
2, 3, 4 4 If 2 is selected, only Day and Nite periods can be programmed. If 3 is
selected, Morn, Day, and Nite can be programmed. If 4 is selected, Morn,
Day, Eve, and Nite can be programmed.
10 Programmable
Fan Operation
0 = Disallowed
1 = Allowed
0 If allowed, Supply Fan operation can be programmed for On or Auto
operation for each programmed period.
11 Remote Sensor
Installed
0 = No
1 = Yes
0 Determines which source will supply the Room Temperature input for
display.
12 Check Filter
Interval
0 = Disabled 3000 to 50
in 50 hour increments
350 Adjustable in 50 hour increments. The CHECK FILTER icon will flash when
the accumulated run time is greater than the interval setting. Pressing the
erase button will reset the counter.
13 Display Zone
Temperature
0 = No
1 = Yes
1 If ZSM is in a Normal Run State or in Temporary Override, the zone
temperature will be displayed.
14 Keypad Lockout
Enabled
0 = Disabled
1 = Enabled
1 When Enabled, Keypad can be locked out.
15 Default Temporary
Override Time
1, 2, 3, 4, 5 3 Sets the default override time in hours.
16 Buzzer Options 0 = Key Press Only
1 = Key Press and Check
Filter
2 = Key Press, Check
Filter, and System Failure
1 Buzzer will sound for a 1/2 sec for every minute if option is set for 1 or 2.
17 Zone Temperature
Calibration
Zone Temperature
Displayed
0 offset This allows for field calibration in 1.0 degree increments of either the
internal sensor on the ZSM or the remote sensor if used.
18 Baud Rate 0 = 1024 baud
1 = 1200 baud
1 Set to Zero for 3 - 25 Ton Voyager Units built before Jan. 1, 1996 that have
the original UCP.
19 CV or HP
Operation
0 = CV
1 = HP
0 This sets the operation MODE for the ZSM. If HP is selected, EMERgency
heat is available.
20 Default Cooling
Set Point
45 to 98 74 If no set point has been programmed or the program is lost, the value set
here becomes the operation set point.
21 Default Heating
Set Point
43 to 96 68 If no set point has been programmed or the program is lost, the value set
here becomes the operation set point.
22 Minimum Cooling
Set Point
45 to 98 45 Sets the minimum programmable cooling temperature set point.
23 Maximum Heating
Set Point
43 to 96 96 Sets the maximum programmable heating temperature set point.
