Create or Edit a Schedule
To create or edit a schedule:
1. Press
, , , , .
Note: Each button shown above must be pressed within 10 seconds
of the
previous button. Once the user is in Schedule Change Mode,
each button must be pressed within 45 seconds of the previous button
in order to stay in Schedule Change Mode.
2. Press or to select the day(s) and
to continue.
Mo Tu We Th Fr Sa Su
AM
We
AM
We
AM
Auto On
3. Press
or to select the period and
to continue.
4. Press
or to change the Start Time
and
to continue.
5. Press
or to change the Heating
Setpoint and
to continue.
6. Press
or to change the Cooling
Setpoint and
to continue.
7. Press
or to select the Fan Setting
and
to continue.
8. Repeat steps 2 through 7 for each day
(see step 2) and p
eriod (see step 3). To
exit Schedule Change Mode, wait 45
seconds or press and hold
for 2
seconds to Save and Exit.
Possible Scheduling Configurations (configuration
option 0233):
• 1 day [default]; MoTuWeThFrSaSu
(all days share a schedule).
• 5+1+1 days; MoTuWeThFr
Sa Su (Monday through Friday share
a schedule, Saturday and Sunday are each separate schedules).
• 5+2 days; MoTuWeThFr SaSu (Mo
nday through Friday share a
schedule, Saturday
and Sunday share a schedule).
• 7 days; Mo Tu We Th Fr Sa Su (
Each day has a separate
schedule).
Note: Use the wo
rksheet on the right for planning or recording schedule
settings. Default settings are ENERGY STAR® compliant.
8:00 am
6:00 am
70
°
F (21.0
°
C)
62
°
F (16.5
°
C)
70
°
F (21.0
°
C)
62
°
F (16.5
°
C)
78
°
F (25.5
°
C)
85
°
F (29.5
°
C)
78
°
F (25.5
°
C)
82
°
F (28.0
°
C)
10:00 pm
6:00 pm
Mo
Tu
We
Th
Fr
Sa
Su
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
°°:
4-Period
defaults
2-Period
defaults
70
°
F (21.0
°
C)
55
°
F (13.0
°
C)
78
°
F (25.5
°
C)
85
°
F (29.5
°
C)
10:00 pm
8:00 am
Morning Day Evening Night Time Heat Cool Fan
ON
BAS-SVN197C-EN 05 Jun 2020
Supersedes X39641168-01B (Mar 2012)
