Global Connector
The Global Connectors facilitate the
connection of terminals and decrease
the interference.
They have aesthetically pleasing;
automotive industry grade; sealed
connector system; easier connection
for factory and field; repeated manual
disconnection and re-connection
allowed.
Figure. 14 - Conector Acoplável
24 Vcc (red wire)
Terra(blk)
IPC + (blue)
IPC + (gray)
IPC + (gray)
IPC + (blue)
Terra(blk)
24 Vcc (red wire)
Figure 15 - Female Plug wire identification (Wire color referenced to round cable)
Figure 16 - Male Plug wire identification (Wire color referenced to round cable)
