CGAD-SVN02C-EN4
Model Number
The product's code describes the configuration, capacity, and optional characteristics. It is very important to
indicate the correct order of the equipment's code in order to avoid future problems when delivering them. Above
you will find the description of each digit that makes up the product code.
Digits 1, 2 - Unit Model
CG = "Cold Generator" Scroll Chiller
Digit 3 - Unit Type
A = Air Cooled
Digit 4 - Model Series
D = Sequence D
Digits 5, 6 e 7 - Nominal Capacity
020 = 20 Ton.
025 = 25 Ton.
030 = 30 Ton.
040 = 40 Ton.
050 = 50 Ton.
060 = 60 Ton.
070 = 70 Ton.
080 = 80 Ton.
090 = 90 Ton.
100 = 100 Ton.
120 = 120 Ton.
150 = 150 Ton.
Digit 8 - Unit Voltage
C = 220/60/3
J = 380/60/3
D = 380-400/50/3
4 = 440-460/60/3
Digit 9 - Manufacturing Location
B = Curitiba Plant - Brazil
Digits 10,11 - Sequence of Modifi. minor of
Project
A0 - Sequence A0 (Defined by factory)
Digit 12 - Certifying Agency
N = No certification
Digit 13 - Refrigerant Type
4 = R407c
Digit 14 - Expansion Valve type
N = Thermostatic
C G A D 1 5 0 J B A 0 N 2 N N A N 0 N N N N N N N N 0 N P 0 0 0 N
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 2 9 30 31 32 33
Digit 15 - Evaporator Application
N = Standard Cooling (40 - 60°F)
Digit 16 - Coil Type
A=Aluminium fins
S = Yellow Fin
Digit 17 - Piping Configuration
N = Standard
A = Service valves on suction and discharge
lines
Digit 18 - Digit Reserved
0 = Reserved
Digit 19 - Feed Type
N = Terminal Block
D = Disconnector Key
C = Circuit Breaker
Digit 20 - Remote Operation Interface
N = No Remote Interface
C = Tracer Comm3 Interface
L = Comm5 - LonTalk Compatible (LCI-C)
Interface
Digit 21 - Input controls
N = No controls
R = External Leaving Water Setpoint
Digit 22 - Output controls
N = No controls
A =Alarm Relay Output
Digit 23 - Electrical Accessories
N = No acessories
Digit 24 - Control Panel Accessories
N = No acessories
Digit 25 - Protection panels
N = NoProtection panels
Digit 26 - Installation accessories
N = Without Installation accessories
R = Neoprene Vibration isolators
F = Adapter Kit for Flange
G = Isolator and Flange adapter kit
Digit 27 - Digit Reserved
0 = Reserved
Digit 28 - Digit Reserved
0 = Reserved
Digit 29 - Language - Literature/Labels
P = Portuguese/Spanish
Digit 30 - Digit Reserved
0 = Reserved
Digit 31 - Digit Reserved
0 = Reserved
Digit 32 - Digit Reserved
0 = Reserved
Digit 33 - Product Type
N = Standard
Z = Special
