Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
CGAX
015
SE-SN
CGAX
017
SE-SN
CGAX
020
SE-SN
CGAX
023
SE-SN
CGAX
026
SE-SN
CGAX
030
SE-SN
CGAX
036
SE-SN
Condenser Fan
Quantity # 1 1 2 2 2 2 2
Diameter (mm) 800
Fan / motor Type Propeller fan : Fixed speed AC motor / Variable speed - EC motor / HESP MAX SPEED
Digit 12=2 or Digit 12=1 and Digit 41=2
Fan / motor Type EC motor / HESP MAX SPEED
Airowperfan m
3
/h 13753 13718 12248 12231 12211 12193 13727
Max Power Input Kw 1,95 1,95 1,95 + 1,95 1,95 + 1,95 1,95 + 1,95 1,95 + 1,95 1,95 + 1,95
Max Amps A 3 3 3 + 3 3 + 3 3 + 3 3 + 3 3 + 3
Motor RPM (rpm) 915 915 915 915 915 915 915
Digit 12=1 and Digit 15=A
Fan / motor Type Fixed speed AC motor / Variable speed - EC motor
Airowperfan m
3
/h 13788 13828 12362 12362 12370 12375 13827
Max Power Input Kw 0,89 0,89 0,89 + 0,89 0,89 + 0,89 0,89 + 0,89 0,89 + 0,89 0,89 + 0,89
Max Amps A 2,22 2,22 2,22 + 2,22 2,22 + 2,22 2,22 + 2,22 2,22 + 2,22 2,22 + 2,22
Motor RPM (rpm) 686 686 686 686 686 686 686
Digit 12=1 and Digit 15=C
Fan / motor Type Fixed speed AC motor / Variable speed - EC motor
Airowperfan m
3
/h 13788 13828 12362 12362 12370 12375 13827
Max Power Input Kw 1,95 1,95 1,95 + 0,89 1,95 + 0,89 1,95 + 0,89 1,95 + 0,89 1,95 + 0,89
Max Amps A 3 3 3 + 2,22 3 + 2,22 3 + 2,22 3 + 2,22 3 + 2,22
Motor RPM (rpm) 686 686 686 686 686 686 686
AirowperFan (m
3
/h) 13788 13828 12362 12362 12370 12375 13827
AirowperFanHESP(915RPM-100Pa) (m
3
/h) 13753 13718 12248 12231 12211 12193 13727
Power per Motor (kW) 686 686 686 686 686 686 686
Partial Heat recovery (PHR) option
Heat-Exchanger Type Stainless steel Copper Brazed plate Heat exchanger
Heat-Exchanger Model
B3-014-14-
4.5M
B3-014-14-
4.5M
B3-014-14-
4.5M
B3-014-14-
4.5M
B3-027-14-
4.5L
B3-027-14-
4.5L
B3-027-14-
4.5L
Water connection size (Thread connection)
(in) -
(mm)
G 1"1/4
(31.75 mm)
G 1"1/4
(31.75 mm)
G 1"1/4
(31.75 mm)
G 1"1/4
(31.75 mm)
G 1"1/4
(31.75 mm)
G 1"1/4
(31.75 mm)
G 1"1/4
(31.75 mm)
Water content volume (l) 0.14 0.14 0.14 0.14 0.35 0.35 0.35
Dimensions (7)
Unit Length (mm) 2346 2346 2346 2346 2346 2346 2327
Unit Width (mm) 1285 1285 1285 1285 1285 1285 2250
Std Unit Height (mm) 1524 1524 1524 1524 1524 1524 1524
LN or External SP unit -
(Additionalheightconguration)
(mm) +223 +224 +225 +226 +227 +228 +229
Water Buffer tank option -
(Additionalheightconguration)
(mm) +330 +330 +330 +330 +330 +330 +330
Weights
Shipping Weight (3) (kg) 519 531 574 579 608 621 853
Operating Weight (3) (kg) 497 509 552 557 587 599 819
Option Additional shipping weight
Single pump - Standard head pressure (kg) 46 46 46 49 49 49 45
Single pump - High head pressure (kg) 51 51 51 51 51 51 49
Twin pump - Standard head pressure (kg) 70 70 70 75 75 75 71
Twin pump - High head pressure (kg) 82 82 82 82 82 82 86
Pump VFD option (kg) 0
Partial heat recovery option (kg) 1.48 1.48 1.48 1.48 3.82 3.82 3.82
Water Buffer tank option (kg) 319 319 319 319 319 319 425
System data
Nb of refrigerant circuit # 1 1 1 1 1 1 1
Minimum cooling load % (6) % 50 43 50 43 50 50 33
Standard/Partial Heat Recovery Unit unit
R410A refrigerant charge Circuit1 / Circuit 2 (kg) 7.5 9.0 9.0 9.0 10.5 10.5 14.0
Oil charge Circuit1 / Circuit 2 (l) 6.0 6.3 6.6 6.6 6.6 7.2 10.5
POE Oil type (6)
OIL058E / OIL057E
(1) Indicative performance at Evaporator water temperature : 12°C / 7°C - Condenser air temperature 35°C - for detailled performances, on a given unit,
consult Order Write Up.
(2) under 400V/3/50Hz.
(3) Rated Condition without Pump Package.
(4) Electrical & system data are indicative and subject to change without notice. Please refer to unit nameplate data.
(5) If the power line of the unit is protected by fuses gG of the same size as the disconnect switch.
(6) OIL058E or 0IL057E are European reference for POE oil and can be mixed in any proportion with OIL00078 or OIL 00080 (same oil with US reference on
compressor nameplate).
(7)Fordimensionsdetails,dimensionsofhydraulicconnections,electricalconnections,pointloadandspecicfeaturesforheatrecoveryseesubmittals
and diagrams which are supplied with every order.
