Trane FC User Manual

UNT-SVX07A-EN 5
Installation
general
information
FC B B 020 1 C P0 A 0 G 1 0 A A 2 M 000 0 0 1 0 0 0 A A 000 000 0 0 0 0 A 0 0
1 5 10 15 20 25 30 35 40 44
Digits 1, 2 — unit type
FC = fan-coil
FF = force flo
Digit 3 — cabinet type
A = vertical concealed
B = vertical cabinet
C = horizontal concealed
D = horizontal cabinet
E = horizontal recessed
F = vertical wall hung
H = vertical recessed
J = vertical cabinet slope top
K = low vertical concealed
L = low vertical cabinet
M = inverted vertical cabinet
N = inverted vertical recessed
Digit 4 — development sequence “B”
Digits 5, 6, 7 — unit size
020 040 080
030 060 100
120
Digit 8 — unit voltage
1 = 115/60/1 4 = 230/60/1
2 = 208/60/1 9 = 220/50/1
3 = 277/60/1
Digit 9 — piping system/placement
A = no piping, RH, w/o aux drn pan
B = no piping, LH, w/o aux drn pan
C = no piping, RH, w/ aux drn pan
D = no piping, LH, w/ aux drn pan
E = no piping, RH, w/o aux drn pan,
extended end pocket
F = no piping, LH, w/o aux drn pan,
extended end pocket
G = no piping, RH, w/ aux drn pan,
extended end pocket
H = no piping, LH, w/ aux drn pan,
extended end pocket
J = piping package, RH
K = piping package, LH
L = piping package, RH, extd end pkt
M = piping package, LH, extd end pkt
Digits 10, 11 — design sequence
Digit 12 — inlets
A = front toe space
B = front bar grille
C = front stamped louver
D = bottom stamped louver
E = bottom toe space
F = back duct collar
G = back open return
H = back stamped louver
Digit 13 — fresh air damper
0 = none
A = manual, bottom opening
B = manual, back opening
C = manual, top opening
D = auto, 2-position, bottom opening
E = auto, 2-position, back opening
F = auto, 2-position, top opening
G = auto, economizer, bottom opening
H = auto, economizer, back opening
J = auto, economizer, top opening
K = no damper, bottom opening
L = no damper, back opening
M= no damper, top opening
Digit 14 — outlets
A = front duct collar
B = front bar grille
C = front stamped louver
D = front quad grille
G = top quad grille
H = top bar grille
J = top duct collar
Digit 15 — color
0 = no paint (concealed units only)
1 = deluxe beige 4 = driftwood grey
2 = soft dove 5 = stone grey
3 = cameo white 6 = rose mauve
Digit 16 — tamperproof locks/leveling
feet
0 = none
A = locking panel
B = keylock access door
C = locking panel & keylock access door
D = leveling feet
F=
locking panel w/ leveling feet
G = keylock panel, keylock access door
w/ leveling feet
Digit 17 — motor
A = free discharge
B = high static
Digit 18 — coil
A = 2 row cooling/heating
B = 3 row cooling/heating
C = 4 row cooling/heating
D = 2 row cooling/1 row heating
E = 2 row cooling/2 row heating
F = 3 row cooling/1 row heating
G = 2 row cooling only
H = 3 row cooling only
J = 4 row cooling only
K = 2 row cooling/heating w/ elec heat
L = 3 row cooling/heating w/ elec heat
M= 4 row cooling/heating w/ elec heat
P = 2 row cooling/heating w/1 row heat
Q = 2 row cooling/heating w/2 row heat
R = 3 row cooling/heating w/1 row heat
Digit 19 — coil series
2 = 144 FPF
Digit 20 — coil air vent
A = automatic air vent
M= manual air vent
Digits 21, 22, 23 — electric heat (208V
derate)
000 = no electric heat
010 = 1.0 kW (0.75 kW)
015 = 1.5 kW (1.1 kW)
020 = 2.0 kW (1.5 kW)
025 = 2.5 kW (1.9 kW)
030 = 3.0 kW (2.3 kW)
040 = 4.0 kW (3.0 kW)
050 = 5.0 kW (3.8 kW)
060 = 6.0 kW (4.5 kW)
070 = 7.0 kW (5.3 kW)
08 0= 8.0 kW (6.0 kW)
100 = 10.0 kW
Digit 24 — reheat coil
0 = none B = hot water coil
A = steam coil
Digit 25 — disconnect switch
0 = none
D = disconnect switch
Digit 26 — filter
0= none
1= 1” throwaway filter
2= 1” throwaway pleated media filter
3= 1” throwaway, qty 2
4=
1” throwaway pltd media, qty 2
5= 1” throwaway, qty 3
6= 1” throwaway pltd media, qty 3
7= 1” throwaway, qty 4
8= 1” throwaway pltd media, qty 4
Digit 27 — main control valve
0 = none
A = 2-way, 2-position, NO (30 psig)
B = 3-way, 2-position, NO (28 psig)
C = 2-way, 2-position, NC (30 psig)
D = 3-way, 2-position, NC (20 psig)
E = 2-way, 2-position, NO (50 psig)
F = 3-way, 2-position, NO (28 psig)
G = 2-way, 2-position, NC (50 psig)
H = 3-way, 2-position, NC (28 psig)
