Trane Foundation GCC 090-150 User Manual

10
RT-SVX069D-EN
Figure 2. Gas/electric units — overview
GAS CONNECTION
INSIDE
CONDENSAT E
DRAIN
CONNECTION
Figure 3. Gas/electric units — front and side views (in inches)
88-7/16”
23-3/4”
48-5/16
”
6-5/16
”
30-3/16
”
14-7/16
”
2-3/4
”
2-3/4
”
44-3/16
”
48-3/4
”
7-3/4”7-3/4”
23-3/4”
58-7/8”
7-3/4” 9-7/8”
2-5/16”
Ø2
Ø1-3/8”
Ø2
Ø1-3/8”
Ø7/8”
7-3/4”
37-15/16”
(GBC UNIT ONLY)
Dimensional Data
