Trane Foundation GCC 090-150 User Manual

RT-SVX069D-EN
11
Figure 4. Gas/electric units — bottom view (in inches)
NOTES:
1.THROUGH THE BASE GAS AND ELECTRICAL IS NOT STANDARD ON ALL UNITS.
2.VERIFY WEIGHT, CONNECTION, AND ALL DIMENSION WITH INSTALLER DOCUMENTS BEFORE INSTALLATION.
29-5/8”
88-7/16”
12-7/16
”
25-5/8”
3-7/16”14”
27-5/16”
37-5/8
”
40-11/16”
12-3/8
”
3-7/16”36-7/16”
Figure 5. Foundation units — back view (horizontal configuration) (in inches)
53-3/16”
4-9/16”
23”
4-15/16”
5-5/8”
36-7/16”
14”
12-3/8”27-5/16”
RETURN
SUPPLY
Dimensional Data
