Trane Foundation GCC 090-150 User Manual

12
RT-SVX069D-EN
Figure 6. Roof curb (in inches)
SUPPLY
RETURN
54 9/16”
54 9/16”
84 13/16”
45 1/8”
84 13/16”
32 1/4”
3.000
3.000
19 3/8”
15 1/2”
15 13/16”
3 9/16”
1 3/4”
14.000
37 15/16”
Figure 7. Downflow unit clearance (in inches)
CLEARANCE
CLEARANCE
CLEARANCE
CLEARANCE
UNIT OUTLINE
54 5/8”
39 11/16”
68”
48”
60”
48”
Dimensional Data
