12
Horizontal Right Configuration
Refrigerant
Connections
Horizontal Left
Condensate
Drains
Low Voltage
Connections
inside unit
Refrigerant
Connections
Horizontal Left Configuration
Low Voltage
Connections
inside unit
Horizontal Right
Condensate Drains
Airflow
Airflow
