Trane GECA -006 - Page 26

26 GECA-SVX01B-EN
Installation
Instructions
Table M-1: Physical Data (GECA 006-012)
Model: GECA 006-012 60 HZ - 006
60 HZ - 009
50 HZ - 006
60 HZ - 012
50 HZ - 009
Unit Size
Length of cabinet (in) 48 or 63 48 or 63 48 or 63
Height (in) 25 or 22 1/2 25 or 22 1/2 25 or 22 1/2
Width (in) 12 12 12
Compressor Type Rotary Rotary Rotary
R-22 Refrigerant (lbs) Heating and Cooling 1.06 1.19 1.22
Cooling Only 0.94 1.06 1.16
Hot Gas Reheat n/a n/a 1.375
Approximate Weight
without Pallet (lbs)
Unit 188 192 204
Chassis Only 140 144 156
Approximate Weight
with Pallet (lbs)
Unit 218 222 234
Chassis Only 170 174 186
Filter Size (standard height-25") 1 x 10 x 32 3/8 1 x 10 x 32 3/8 1 x 10 x 32 3/8
Filter Size (low height-22 1/2") 1 x 7 3/4 x 30 5/8 1 x 7 3/4 x 30 5/8 1 x 7 3/4 x 30 5/8
Blower Wheel Size (in) (1) 5 1/4 x 8 1/8 (2) 5 1/4 x 8 1/8 (2) 5 1/4 x 8 1/8
Table M-2: Physical Data (GECA 015-24)
Model: GECA 015-018
60 HZ - 015
50 HZ - 012
60 HZ - 018
50 HZ - 015
Unit Size
Length of cabinet (in) 48 or 63 48 or 63
Height (in) 25 or 22 1/2 25 or 22 1/2
Width (in) 12 12
Compressor Type Rotary Rotary
R-22 Refrigerant (lbs) Heating and Cooling 1.75 2.44
Cooling Only 1.5 1.88
Hot Gas Reheat n/a n/a
Approximate Weight
without Pallet (lbs)
Unit 203 210
Chassis Only 155 162
Approximate Weight
with Pallet (lbs)
Unit 233 240
Chassis Only 185 192
Filter Size (standard height-25") 1 x 10 x 32 3/8 1 x 10 x 32 3/8
Filter Size (low height-22 1/2") 1 x 7 3/4 x 30 5/8 1 x 7 3/4 x 30 5/8
Blower Wheel Size (in) (2) 5 1/4 x 8 1/8 (2) 5 1/4 x 8 1/8
