Electrical Requirements
Units w/o Pump Kit
Table E-1: GECA electrical performance
Model No.
GECA
Volts Total
FLA
Comp.
RLA
(ea)
Comp.
LRA
(ea)
No. of
Compres.
Cmp
MCC
Blower
Motor
FLA
Blower
Motor
HP
Fan
Motor
Num
Minimum
Circuit
Ampacity
Overcurrent
Protective
Device
Electric Heat
SIZE kW Amps
006
115/60/1 6.5 5.6 36.2 1 9.1 0.90 1/20 1 8.2 15 None 0 0
208/60/1 3.6 2.76 17.7 1 4.6 0.80 1/20 1 4.5 15 None 0 0
208/60/1 11.6 2.76 17.7 1 4.6 0.80 1/20 1 14.5 15 Min 2.25 10.82
208/60/1 15.2 2.76 17.7 1 4.6 0.80 1/20 1 19.0 20 Max 3 14.42
230/60/1 3.5 2.76 17.7 1 4.6 0.70 1/20 1 4.4 15 None 0 0
230/60/1 13.2 2.76 17.7 1 4.6 0.70 1/20 1 16.5 20 Min 3 12.5
220-240/50/1 3.8 3.10 18.8 1 5.2 0.70 1/20 1 4.9 15 None 0 0
220-240/50/1 13.2 3.10 18.8 1 5.2 0.70 1/20 1 16.5 20 Min 3 12.5
265/60/1 3.2 2.45 15.0 1 3.9 0.70 1/20 1 3.8 15 None 0 0
265/60/1 11.5 2.45 15.0 1 3.9 0.70 1/20 1 14.4 15 Min 3 10.83
009
115/60/1 8.1 7.20 45.6 1 10.9 0.90 1/20 1 9.9 15 None 0 0
208/60/1 4.2 3.40 22.2 1 6.4 0.80 1/20 1 5.9 15 None 0 0
208/60/1 11.6 3.40 22.2 1 6.4 0.80 1/20 1 14.5 15 Min 2.25 10.82
208/60/1 15.2 3.40 22.2 1 6.4 0.80 1/20 1 19.0 20 Max 3 14.42
230/60/1 4.1 3.40 22.2 1 6.4 0.70 1/20 1 5.8 15 None 0 0
230/60/1 13.2 3.40 22.2 1 6.4 0.70 1/20 1 16.5 20 Min 3 12.5
230/60/1 17.4 3.40 22.2 1 6.4 0.70 1/20 1 21.7 25 Max 4 16.67
220-240/50/1 5.0 4.30 22.2 1 6.6 0.70 1/12 1 6.1 15 None 0 0
220-240/50/1 13.2 4.30 22.2 1 6.6 0.70 1/12 1 16.5 20 Min 3 12.5
220-240/50/1 17.4 4.30 22.2 1 6.6 0.70 1/12 1 21.7 25 Max 4 16.67
265/60/1 3.8 3.10 18.8 1 5.2 0.70 1/20 1 4.9 15 None 0 0
265/60/1 11.5 3.10 18.8 1 5.2 0.70 1/20 1 14.4 15 Min 3 10.83
265/60/1 15.1 3.10 18.8 1 5.2 0.70 1/20 1 18.9 20 Max 4 14.44
012
115/60/1 11.8 10.60 56.7 1 16.0 1.20 1/12 1 14.5 25 None 0 0
208/60/1 5.9 5.00 27.9 1 8.3 0.90 1/12 1 7.6 15 None 0 0
208/60/1 11.7 5.00 27.9 1 8.3 0.90 1/12 1 14.7 15 Min 2.25 10.82
208/60/1 15.3 5.00 27.9 1 8.3 0.90 1/12 1 19.2 20 Max 3 14.42
230/60/1 5.7 5.00 27.9 1 8.3 0.70 1/12 1 7.4 15 None 0 0
230/60/1 13.2 5.00 27.9 1 8.3 0.70 1/12 1 16.5 20 Min 3 12.5
230/60/1 17.4 5.00 27.9 1 8.3 0.70 1/12 1 21.7 25 Max 4 16.67
220-240/50/1 5.5 4.80 27.0 1 8.5 0.70 1/12 1 7.5 15 None 0 0
220-240/50/1 13.2 4.80 27.0 1 8.5 0.70 1/12 1 16.5 20 Min 3 12.5
220-240/50/1 17.4 4.80 27.0 1 8.5 0.70 1/12 1 21.7 25 Max 4 16.67
265/60/1 5.0 4.30 22.2 1 6.6 0.70 1/12 1 6.1 15 None 0 0
265/60/1 11.5 4.30 22.2 1 6.6 0.70 1/12 1 14.4 15 Min 3 10.83
265/60/1 15.1 4.30 22.2 1 6.6 0.70 1/12 1 18.9 20 Max 4 14.44
015
115/60/1 12.6 11.40 67.0 1 17.6 1.20 1/12 1 15.5 25 None 0 0
208/60/1 6.4 5.40 29.0 1 9.2 1.00 1/12 1 8.4 15 None 0 0
208/60/1 11.8 5.40 29.0 1 9.2 1.00 1/12 1 14.8 15 Min 2.25 10.82
208/60/1 15.4 5.40 29.0 1 9.2 1.00 1/12 1 19.3 20 Max 3 14.42
230/60/1 6.3 5.40 29.0 1 9.2 0.90 1/12 1 8.3 15 None 0 0
230/60/1 13.4 5.40 29.0 1 9.2 0.90 1/12 1 16.8 20 Min 3 12.5
230/60/1 17.6 5.40 29.0 1 9.2 0.90 1/12 1 22.0 25 Max 4 16.67
220-240/50/1 6.1 5.40 32.0 1 8.6 0.70 1/12 1 7.6 15 None 0 0
220-240/50/1 13.2 5.40 32.0 1 8.6 0.70 1/6 1 16.5 20 Min 3 12.5
220-240/50/1 17.4 5.40 32.0 1 8.6 0.70 1/6 1 21.7 25 Max 4 16.67
265/60/1 5.5 4.80 27.0 1 8.5 0.70 1/6 1 7.5 15 None 0 0
265/60/1 11.5 4.80 27.0 1 8.5 0.70 1/12 1 14.4 15 Min 3 10.83
265/60/1 15.1 4.80 27.0 1 8.5 0.70 1/12 1 18.9 20 Max 4 14.44
018
208/60/1 7.4 6.40 38.0 1 11.0 1.00 1/12 1 9.8 15 None 0 0
208/60/1 11.8 6.40 38.0 1 11.0 1.00 1/6 1 14.8 15 Min 2.25 10.82
208/60/1 15.4 6.40 38.0 1 11.0 1.00 1/6 1 19.3 20 Max 3 14.42
230/60/1 7.3 6.40 38.0 1 11.0 0.90 1/6 1 9.7 15 None 0 0
230/60/1 13.4 6.40 38.0 1 11.0 0.90 1/6 1 16.8 20 Min 3 12.5
230/60/1 17.6 6.40 38.0 1 11.0 0.90 1/6 1 22.0 25 Max 4 16.67
265/60/1 6.1 5.40 32.0 1 8.6 0.70 1/6 1 7.6 15 None 0 0
265/60/1 11.5 5.40 32.0 1 8.6 0.70 1/6 1 14.4 15 Min 3 10.83
265/60/1 15.1 5.40 32.0 1 8.6 0.70 1/6 1 18.9 20 Max 4 14.44
