Pump Kit Information
The pump module is a self-contained pumping package for earth-coupled heat pump systems. This kit contains the
components for the operation of a closed-loop earth-coupled heat pump water circuit system. The kit contains:
• One Grundfos pump 1/6 HP, 230V, 1PH
• Pump rated at 16 GPM at 20-feet of head
• 3-way brass shut-off valve
• Insulated cabinet
See Pump Module Kit manual WSHPC-IN-5 (72-9006-03) for pump module start-up and maintenance.
Table E-2: GECA electrical performance
Model No.
GECA
60 HZ
Volts Total
FLA
Comp.
RLA
(ea)
Comp.
LRA
(ea)
No. of
Compr.
Cmp
MCC
Blower
Motor
FLA
Blower
Motor
HP
Fan
Motor
Num
Minimum
Circuit
Ampacity
Overcurrent
Protective
Device
Electric Heat
SIZE kW Amps
006
230/60/1 3.5 2.76 17.7 1 4.6 0.70 1/20 1 5.5 15 None 0 0
230/60/1 13.2 2.76 17.7 1 4.6 0.70 1/20 1 16.5 20 Min 3 12.5
009
230/60/1 4.1 3.40 22.2 1 6.4 0.70 1/20 1 6.9 15 None 0 0
230/60/1 13.2 3.40 22.2 1 6.4 0.70 1/20 1 16.5 20 Min 3 12.5
230/60/1 17.4 3.40 22.2 1 6.4 0.70 1/20 1 21.7 25 Max 4 16.67
012
230/60/1 5.7 5.00 27.9 1 8.3 0.70 1/12 1 8.4 15 None 0 0
230/60/1 13.2 5.00 27.9 1 8.3 0.70 1/12 1 16.5 20 Min 3 12.5
230/60/1 17.4 5.00 27.9 1 8.3 0.70 1/12 1 21.7 25 Max 4 16.67
015
230/60/1 6.3 5.40 29.0 1 9.2 0.90 1/12 1 9.3 15 None 0 0
230/60/1 13.4 5.40 29.0 1 9.2 0.90 1/12 1 16.8 20 Min 3 12.5
230/60/1 17.6 5.40 29.0 1 9.2 0.90 1/12 1 22 25 Max 4 16.67
018
230/60/1 7.3 6.40 38.0 1 11.0 0.90 1/6 1 10.8 15 None 0 0
230/60/1 13.4 6.40 38.0 1 11.0 0.90 1/6 1 16.8 20 Min 3 12.5
230/60/1 17.6 6.40 38.0 1 11.0 0.90 1/6 1 22.0 25 Max 4 16.67
