Trane GECA -006 - Dimensions and Weights; Unit Clearance Requirements

GECA-SVX01B-EN 5
Dimensions/
Weights
Unit
Size
without Pallet with Pallet
60 HZ 50 HZ
Unit
Weight
(lbs)
Chassis
Weight
(lbs)
Unit
Weight
(lbs)
Chassis
Weight
(lbs)
006 - 188 140 218 170
009 006 192 144 222 174
012 009 204 156 234 186
015 012 203 155 233 185
018 015 210 162 240 192
Unit Clearance
Access to the unit for servicing purposes should be provided at installation. All configurations require clear-
ance from other mechanical and electrical equipment on three service sides (shown below). This enables
panel removal from the unit for service/maintenance ability.
