Operating Data
Model
GEVA
Entering
Water Temp,
°F
Water
Flow
GPM
Cooling Heating
Suction Pres-
sure,
PSIG
Discharge
Pressure,
PSIG
Water
Temp Rise
°F
Air Temp
Drop
°F DB
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Water Temp
Drop
°F
Air Temp
Rise
°F DB
60HZ
018
50 HZ
015
35° 3.8 37-43 165-207 4-6 20-26
4.8 38-44 167-209 3-5 21-27
45° 3.8 73-85 106-138 10-14 23-29 48-56 174-220 5-7 23-29
4.8 74-84 103-133 8-12 23-29 50-58 176-222 4-6 23-31
55° 3.8 74-86 126-162 9-13 23-29 57-67 184-232 6-8 26-34
4.8 75-85 123-159 7-11 23-29 60-70 187-235 5-7 26-34
68° 3.8 75-87 143-185 9-13 23-29 71-81 198-250 8-10 30-38
4.8 75-87 139-179 7-11 23-29 74-84 202-254 6-8 31-39
75° 3.8 75-87 161-207 9-13 22-28 78-90 206-260 8-10 32-42
4.8 75-87 157-201 7-11 22-28 82-94 211-265 7-9 33-43
86° 3.8 76-88 192-246 9-13 22-28 91-105 221-277 9-13 36-46
4.8 76-88 187-239 7-11 22-28 95-109 225-283 7-11 37-47
95° 3.8 77-89 219-281 9-13 22-28
4.8 77-89 212-272 7-11 22-28
Sequence of
Operation
