44 WSHP-PRC001-EN
Model
Number
DIGITS 1-3: UNIT
CONFIGURATION
GEH = High Efficiency Horizontal
GEV = High Efficiency Vertical
DIGIT 4: DEVELOPMENT
SEQUENCE B
DIGITS 5-7: NOMINAL CAPACITY
006 = 1/2 Ton
009 = 3/4 Ton
012 = 1 Ton
015 = 1 1/4 Ton
018 = 1 1/2 Ton
024 = 2 Ton
030 = 2 1/2 Ton
036 = 3 Ton
040 = 3 1/3 Ton (vertical ONLY)
DIGIT 8: VOLTAGE (Volts/Hz/Phase)
1 = 208/60/1 6 = 220-240/50/1
2 = 230/60/1 7 = 265/60/1
3 = 208/60/3 8 = 230/60/3
4 = 460/60/3 9 = 380-415/50/3
5 = 575/60/3
DIGITS 9: HEAT EXCHANGER
1 = Copper-Water Coil
2 = Cupro-Nickel Water Coil
DIGITS 10: CURRENT DESIGN
SEQUENCE
DIGITS 11: REFRIGERATION
CIRCUIT
0 = Heating and Cooling Circuit
2 = Heating and Cooling Circuit
with Hot Gas Reheat
3 = Heating and Cooling Circuit
with Waterside Economizer
4 = Heating and Cooling Circuit
with HGR and WSE
A = Cooling ONLY Circuit
C = Cooling ONLY Circuit
with Hot Gas Reheat
D = Cooling ONLY Circuit
with Waterside Economizer
E = Cooling ONLY Circuit
with HGR and WSE
DIGITS 12: BLOWER
CONFIGURATION
1/2 through 5 Ton Units
1 = Standard Blower Motor
2 = High Static Blower Motor
12 1/2 through 25 Ton Units
A = Drive Package A
B = Drive Package B
C = Drive Package C
D = Drive Package D
E = Drive Package E
F = Drive Package F
G = Drive Package G
H = Drive Package H
J = Drive Package J
DIGIT 13: CUSTOMER CHANNEL
1 = Boiler/Tower Design for Trane
Commercial Group
2 = Geothermal Design for Trane
Commercial Group
5 = Trane International Group
DIGIT 14: OPEN DIGIT = 0
DIGIT 15: SUPPLY-AIR
ARRANGEMENT
B = Back Supply-Air Arrangement
F = Front Supply-Air Arrangement
L = Left Supply-Air Arrangement
R = Right Supply-Air Arrangement
T = Top Supply-Air Arrangement
DIGIT 16: RETURN-AIR
ARRANGEMENT
B = Back Return-Air Arrangement
F = Front Return-Air Arrangement
L = Left Return-Air Arrangement
R = Right Return-Air Arrangement
DIGIT 17: CONTROL TYPES
0 = Basic 24 V Controls
D = Deluxe 24 V Controls
C = Tracer ZN510 Controls
B = Tracer ZN524 Controls
DIGITS 18: TSTAT/SENSOR
LOCATION
0 = Wall Mounted Location
DIGITS 19: FAULT SENSORS
0 = No Fault Sensor
1 = Condensate Overflow Sensor
2 = Filter Maintenance Timer
3 = Condensate Overflow and Filter
Maitenance Timer
4 = Fan Status Sensor
6 = Condensate Overflow and Fan
Status
H = Fan Status and Filter
Maintenance Timer
J = Fan Status, Filter Maintenance
Timer and Condensate Overflow
Sensor
DIGITS 20: TEMPERATURE
SENSOR
0 = No Additional Temperature
Sensor
1 = Entering Water Sensor
DIGITS 21: NIGHT SETBACK
CONTROL
0 = No Night Setback Relay
N = Night Setback Relay
DIGITS 22: ELECTRIC HEAT
0 = No Electric Heat
1 = Internal Boilerless Electric Heat
4 = External Boilerless Electric Heat
5 = External Supplemental Electric
Heat
Horizontal/Vertical Water-Source Comfort System
5 10 15 20
G E H B 036 1 1 D 0 1 1 0 D L D 0 1 0 N 0 0 1 1 0 0 0 1 0 0 0 0 000
30
25
042 = 3 1/2 Ton
048 = 4 Ton
060 = 5 Ton
150 = 12 1/2 Ton
180 = 15 Ton
240 = 20 Ton
300 = 25 Ton
