Trane GEH 006 - Performance Data; Cool and Heat Performance

WSHP-PRC001-EN 49
Table P1: ARI-ISO Performance
Performance data is tabulated for cooling at 80.6 F DB/66.2 F WB entering air, and for heating at 68 F DB entering air at ARI/ISO 13256-1
rated CFM.
For conditions other than what is tabulated, multipliers must be used to correct performance. See the Fan Correction Factor Tables for
CFM other than rated, and the Cooling or Heating correction factors for variations in entering air temperature. Data shown below is per-
formance data at ARI/ISO 13256.1 WLHP and GLHP water only conditions. Antifreeze correction factors may be found on page 108.
Unit Size Rated Flow
Rate, GPM
Rated Air
Flow,
SCFM
cooling
capacity,
WLHP
(Mbtuh)
EER
WLHP
Heating
capacity,
WLHP
(Mbtuh)
COP
WLHP
cooling
capacity,
GLHP
(Mbtuh)
EER
GLHP
Heating
capacity,
GLHP
(Mbtuh)
COP
GLHP
006 1.5 190 7.0 13.0 8.9 4.3 7.3 15.2 5.7 3.2
009 2.1 285 8.6 12.9 11.1 4.6 9.0 15.3 7.1 3.4
012 2.8 380 12.2 13.2 13.5 4.4 12.7 15.0 9.5 3.4
015 3.5 460 13.8 14.0 17.5 4.8 14.6 16.6 11.1 3.7
018 4.2 570 18.6 13.5 22.1 4.5 19.4 15.7 14.2 3.4
024 5.5 760 25.2 12.6 31.0 4.4 26.8 14.6 19.4 3.4
030 6.9 900 28.1 12.5 33.5 4.3 29.8 14.2 21.3 3.3
036 8.3 1140 34.9 13.7 43.1 4.7 35.9 15.2 25.2 3.5
GEV 040 9.2 1200 37.9 12.7 44.9 4.1 39.9 14.3 27.5 3.2
042 9.7 1330 39.5 12.1 48.5 4.2 41.6 13.6 29.9 3.3
048 11.0 1520 47.3 12.8 57.0 4.3 49.8 14.4 35.1 3.2
060 14.5 1900 57.9 12.8 73.8 4.5 60.1 14.5 47.2 3.3
GEV 150 @ .35 ESP 37.5 5000 141.7 15.5 173.7 5.5 146.0 17.3 108.8 3.9
GEV 180 @ .35 ESP 45.0 6000 170.8 13.0 212.6 4.8 176.2 14.5 132.3 3.5
GEV 240 @ .40 ESP 60.0 8000 246.0 13.1 281.1 4.3 253.4 14.5 192.2 3.4
GEV 300 @ .45 ESP 75.0 10000 274.2 11.6 348.0 4.1 283.6 12.6 230.7 3.2
GEV 300 @ .65 ESP 75.0 10000 274.2 12.1 348.0 4.2 283.6 13.2 230.7 3.3
Performance Data
ARI-ISO (WLHP/GLHP)
