Trane GEH 006 - Page 48

48 WSHP-PRC001-EN
Table G8: GEH/GEV 006, 009
Table G9: GEH/GEV 012
Table G10: GEH/GEV 015
Table G11: GEH 018, 024, 030
Working Pressure 425
Tubes High 14
Tubes Deep 2
No. of Circuits 1
Finned vol. (h,w,d) 14 x 16 x 1.734
Coil Surface Area (Ft
2
) 1.56
Fins Per Inch 12
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 14
Tubes Deep 3
No. of Circuits 2
Finned vol. (h,w,d) 14 x 16 x 2.598
Coil Surface Area (Ft
2
) 1.56
Fins Per Inch 12
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 14
Tubes Deep 3
No. of Circuits 1
Finned vol. (h,w,d) 14 x 16 x 2.598
Coil Surface Area (Ft
2
) 1.56
Fins Per Inch 12
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 16
Tubes Deep 4
No. of Circuits 4
Finned vol. (h,w,d) 16 x 19 x 3.464
Coil Surface Area (Ft
2
) 2.11
Fins Per Inch 12
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Table G12: GEV 018, 024, 030, 040
Table G13: GEH/GEV 036, 042
Table G14: GEH 048, 060
Table G15: GEV 048, 060
Working Pressure 425
Tubes High 21
Tubes Deep 4
No. of Circuits 4
Finned vol. (h,w,d) 21 x 16 x 3.464
Coil Surface Area (Ft
2
) 2.33
Fins Per Inch 12
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 18
Tubes Deep 4
No. of Circuits 6
Finned vol. (h,w,d) 18 x 21 x 3.464
Coil Surface Area (Ft
2
) 2.63
Fins Per Inch 12
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 20
Tubes Deep 4
No. of Circuits 8
Finned vol. (h,w,d) 20 x 29 x 3.464
Coil Surface Area (Ft
2
) 4.03
Fins Per Inch 12
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 24
Tubes Deep 4
No. of Circuits 8
Finned vol. (h,w,d) 24 x 25 x 3.464
Coil Surface Area (Ft
2
) 4.17
Fins Per Inch 12
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Table G16: GEV 150 (dual compr. circuit)
Table G17: GEV 180 (dual compr. circuit)
Table G18: GEV 240, 300
(dual compr. circuit)
Working Pressure 425
Tubes High 28
Tubes Deep 2
No. of Circuits 7 refrig flow paths (2X)
Finned vol. (h,w,d) 28 x 73 x 1.734
Coil Surface Area (Ft
2
) 14.19
Fins Per Inch 14
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 32
Tubes Deep 3
No. of Circuits 9 refrig flow paths (2X)
Finned vol. (h,w,d) 32 x 73 x 2.598
Coil Surface Area (Ft
2
) 16.22
Fins Per Inch 14
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
Working Pressure 425
Tubes High 36
Tubes Deep 4
No. of Circuits 18 refrig flow paths (2X)
Finned vol. (h,w,d) 36x 73 x 3.464
Coil Surface Area (Ft
2
) 18.25
Fins Per Inch 14
Tube Material Copper
Tube OD (in) 3/8
Wall Thickness 0.014
Return Bends Copper
General Data
Air-to-Refrigerant Coils
