Performance Data
006-Cooling
Table P2: GEH/GEV 006 Cooling Performance
Performance data is tabulated for cooling at 80.6 F DB/66.2 F WB entering air at ARI/ISO 13256-1 rated CFM.
For conditions other than what is tabulated, multipliers must be used to correct performance. See the fan correction factors Table for CFM
other than rated and the cooling correction factors for variations in entering air temperature. Data shown in bold type is performance data
at ARI/ISO 13256-1 WLHP and GLHP water only conditions. Antifreeze correction factors may be found on page 108.
RATED GPM: 1.5 MINIMUM CFM: 152
RATED CFM: 190 MAXIMUM CFM: 228
EWT GPM Total
Mbtuh
Sen
Mbtuh
SHR Power
kW
Reject
Mbtuh
LWT Ft.
Hd.
CFM ISO Cap
Mbtuh
ISO Pwr
kW
ISO
EER
45
1.0 8.4 5.5 0.66 0.46 10.0 65.0 1.5
190
8.6 0.42 20.4
1.2 8.4 5.6 0.66 0.45 10.0 61.6 2.1 8.6 0.41 21.0
1.4 8.5 5.6 0.66 0.45 10.0 59.3 2.7 8.6 0.41 21.0
1.5 8.5 5.6 0.66 0.44 10.0 58.3 3.0 8.6 0.40 21.6
1.6 8.5 5.6 0.66 0.44 10.0 57.5 3.4 8.6 0.40 21.6
1.7 8.5 5.6 0.66 0.43 10.0 56.7 3.7 8.6 0.39 22.2
1.8 8.5 5.6 0.66 0.43 10.0 56.1 4.1 8.7 0.39 22.2
55
1.0 8.0 5.4 0.68 0.46 9.5 74.1 1.4
190
8.1 0.42 19.3
1.2 8.0 5.4 0.68 0.45 9.5 70.9 2.0 8.2 0.41 19.9
1.4 8.0 5.5 0.68 0.45 9.6 68.7 2.6 8.2 0.41 20.0
1.5 8.1 5.5 0.68 0.44 9.6 67.8 2.9 8.2 0.40 20.6
1.6 8.1 5.5 0.68 0.44 9.6 67.0 3.2 8.2 0.40 20.6
1.7 8.1 5.5 0.68 0.44 9.6 66.3 3.5 8.3 0.40 20.6
1.8 8.1 5.6 0.69 0.43 9.6 65.6 3.9 8.3 0.39 21.2
68
1.0 7.4 5.3 0.71 0.50 9.2 86.3 1.4
190
7.6 0.46 16.5
1.2 7.5 5.3 0.71 0.49 9.2 83.3 1.9 7.7 0.45 17.0
1.4 7.6 5.4 0.71 0.48 9.2 81.1 2.4 7.7 0.44 17.5
1.5 7.6 6.0 0.80 0.48 9.2 80.3 2.7 7.7 0.44 17.6
1.6 7.6 5.4 0.71 0.47 9.2 79.5 3.0 7.8 0.43 18.0
1.7 7.6 5.4 0.71 0.47 9.2 78.9 3.3 7.8 0.43 18.1
1.8 7.7 5.5 0.71 0.47 9.3 78.3 3.6 7.8 0.43 18.2
GLHP
77
1.0 7.1 5.2 0.73 0.55 9.0 95.0 1.3
190
7.3 0.51 14.3
1.2 7.2 5.2 0.73 0.54 9.0 92.1 1.8 7.3 0.50 14.7
1.4 7.3 5.3 0.73 0.53 9.1 90.0 2.3 7.4 0.49 15.1
1.5 7.3 5.3 0.73 0.53 9.1 89.2 2.6 7.4 0.49 15.2
1.6 7.3 5.3 0.73 0.52 9.1 88.4 2.9 7.5 0.48 15.6
1.7 7.3 5.4 0.73 0.52 9.1 87.8 3.1 7.5 0.48 15.6
1.8 7.4 5.4 0.73 0.52 9.1 87.2 3.4 7.5 0.48 15.7
WLHP
86
1.0 6.8 5.1 0.74 0.61 8.9 103.9 1.3
190
7.0 0.56 12.4
1.2 6.9 5.2 0.75 0.60 8.9 101.0 1.7 7.1 0.55 12.8
1.4 7.0 5.2 0.75 0.59 9.0 98.9 2.2 7.1 0.55 12.9
1.5 7.0 5.3 0.75 0.59 9.0 98.1 2.5 7.2 0.55 13.0
1.6 7.0 5.3 0.75 0.59 9.1 97.4 2.7 7.2 0.55 13.1
1.7 7.1 5.3 0.75 0.58 9.1 96.7 3.0 7.2 0.54 13.4
1.8 7.1 5.3 0.75 0.58 9.1 96.1 3.3 7.3 0.54 13.4
95
1.0 6.5 5.0 0.76 0.67 8.8 112.8 1.2
190
6.7 0.63 10.6
1.2 6.6 5.1 0.77 0.67 8.9 109.9 1.6 6.8 0.63 10.8
1.4 6.7 5.2 0.77 0.66 9.0 107.9 2.1 6.9 0.62 11.1
1.5 6.7 5.2 0.77 0.65 9.0 107.0 2.4 6.9 0.61 11.3
1.6 6.8 5.2 0.77 0.65 9.0 106.3 2.6 6.9 0.61 11.4
1.7 6.8 5.3 0.77 0.65 9.0 105.7 2.9 7.0 0.61 11.4
1.8 6.9 5.3 0.77 0.64 9.0 105.1 3.2 7.0 0.60 11.7
105
1.0 6.2 4.9 0.79 0.74 8.4 122.7 1.2
190
6.4 0.69 9.3
1.2 6.3 5.0 0.79 0.74 8.6 119.9 1.6 6.5 0.69 9.4
1.4 6.4 5.1 0.79 0.73 8.8 117.8 2.0 6.6 0.69 9.6
1.5 6.5 5.1 0.79 0.72 9.0 117.0 2.2 6.6 0.68 9.8
1.6 6.5 5.2 0.79 0.72 9.1 116.3 2.5 6.7 0.68 9.8
1.7 6.6 5.2 0.79 0.72 9.1 115.7 2.8 6.7 0.68 9.9
1.8 6.6 5.2 0.79 0.71 9.3 115.1 3.0 6.8 0.67 10.1
115
1.0 6.0 4.9 0.81 0.84 8.8 132.9 1.1
190
6.1 0.79 7.8
1.2 6.1 5.0 0.82 0.83 8.9 130.0 1.5 6.2 0.78 8.0
1.4 6.2 5.1 0.82 0.82 9.0 128.0 1.9 6.3 0.78 8.1
1.5 6.2 5.1 0.82 0.82 9.0 127.2 2.2 6.4 0.78 8.2
1.6 6.3 5.1 0.82 0.81 9.0 126.4 2.4 6.4 0.77 8.4
1.7 6.3 5.2 0.82 0.81 9.1 125.8 2.7 6.5 0.77 8.4
1.8 6.4 5.2 0.82 0.81 9.1 125.2 3.0 6.5 0.77 8.5
120
1.0 5.8 4.8 0.82 0.91 9.0 138.1 1.0
190
6.0 0.86 7.0
1.2 6.0 4.9 0.83 0.90 9.0 135.2 1.4 6.1 0.85 7.2
1.4 6.1 5.0 0.83 0.90 9.1 133.2 1.9 6.2 0.86 7.3
1.5 6.1 5.1 0.83 0.89 9.1 132.3 2.1 6.3 0.85 7.4
1.6 6.2 5.1 0.83 0.89 9.2 131.6 2.4 6.3 0.85 7.4
1.7 6.2 5.2 0.83 0.88 9.2 131.0 2.6 6.4 0.84 7.6
1.8 6.2 5.2 0.83 0.88 9.3 130.4 2.9 6.4 0.84 7.6
