PKG-SVP01B-EN
73
Programming
DIAGNOSTICS
OR
Active Diagnostic ---- Auto Reset
______________________________ More
Possible Values: Failure for the Following
RTM Zone Heat Aux Temp
Supply Air Temp Unocc Zone Cool Setpt
RTM Aux. Temp Unocc Zone Heat Setpt
OA Temp Supply Air Press Setpt
Mode Input Space Static Pres Setpt
Occ Zone Cool Setpoint Space Pressure
Occ Zone Heat Setpoint Return Air Temp
Supply air Pres RA Humidity
OA Humidity Auto Reset SA Static Pres Limit
SCM Communication Evap Temp - Ckt 1, 2, 3, 4
MCM Communication Heat Module Commun.
ECEM Communication Cond Temp - Ckt 1, 2, 3, 4
TCI Communication GBAS Module Communication
Tracer
®
Communication NSB Panel Communication
Unit HI Communication VOM Communication
Sup Air Temp Cool Setpt Sup Air Temp Heat Setpt
NSB Panel Zone Temp CO2 Sensor
VCM Aux Temp Velocity Press
VCM Communication WSM Communication
Ent Cond Water Temp Ent Water Temp
WSM Mixed Air Temp Water Flow
OR
Pressing the NEXT key to view the diagnostics will prompt the following screen if an
“information only” failure has occurred.
Active Diagnostic ---- Info
______________________________ More
Possible Values: Heat Fail
Dirty Filter
Ventilation Override Mode A, B, C, D, or E
RTM Data Storage Error
Note: Activation of any VOM mode can be viewed within the “Active Diagnostic” screen.
