General
Information
About This Manual
Literature Change History
Use this manual for IntelliPak
®
commer-
cial self-contained models SCWF/SIWF,
SCRF/SIRF, SCWG/SIWG, and SIWG/
SIRG. This is the second issue of this
manual. This revision includes an index,
which was not in the original issue.
It provides specific programming
instructions for “AO” and later design
sequences. For previous design
sequences, contact your local Trane
representative.
Overview
This manual is divided into multiple
sections based on the unit’s human
interface (HI) panel format. Each section
provides step by step instructions for
programming the unit using the HI. In
addition, each section provides specific
information about the system operating
parameters and their related HI screens,
in the order they appear when scrolling
through the HI.
By carefully following the screen layout
in this manual while referencing the HI
panel, the user can monitor operating
Note: One copy of the appropriate service
literature (Installation, Owner, and Diagnos-
tic Manual) ships inside the control panel
of each unit.
status, set specific operating parameters,
and diagnose system problems.
Some screens shown in this manual are
dependent on unit options and/or model
configuration. Therefore, some screens in
this manual may not appear on a
particular unit’s human interface panel.
Screens that are configuration-depen-
dent are labeled as such. Follow the
appropriate steps for each screen as it
appears and proceed through each
section.
Refer to the table of contents and index
for specific topics contained in this
manual and supporting manuals.
Complete the “Start-Up” procedures in
the applicable Installation, Owner, and
Diagnostic (IOD) manual before attempt-
ing to operate or service this equipment
to minimize the risk of improper opera-
tion.
Note: The procedures discussed in this
manual should only be performed by
qualified, experienced HVAC technicians.
