Table 8. Return Duct Connections (continued)
Downflow Modular Blower with Top Return
1. Remove the top plate.
2. Attach the ducting to the top of the modular blower.
3. Install remote filter.
4. Seal per local codes and requirements.
Downflow Modular Blower with Top Return and Plenum
1. Remove the top plate.
2. Attach the plenum ducting to the top of the modular blower.
3. Install remote filter.
4. Seal per local codes and requirements.
