Trane P0V0 Series Installer's Guide

18-GE20D1-1E-EN
5
Features and Accessories
Table 1. Standard Features
• MULTI-POSITION UPFLOW, DOWNFLOW, HORIZONTAL LEFT
AND HORIZONTAL RIGHT
• PAINTED FINISH ON GALVANIZED STEEL EXTERIOR WITH
FULLY INSULATED CABINET THAT MEETS 4.0 R VALUE.
BLOWER COMPARTMENT INSULATION IS ONLY INSTALLED
IN B, C AND D SIZE PRODUCTS AND HAS A 2.1 R VALUE
• 120 VAC OPERATION
• VARIABLE SPEED DIRECT DRIVE BLOWER
• SIDE AND BOTTOM RETURN
• MEETS THE MINIMUM LEAKAGE REQUIREMENTS FOR THE
FLORIDA AND CALIFORNIA BUILDING CODES
Table 2. Accessories
Model Number Description Use with
BAYHANG Horizontal Hanging Kit All modular blowers
BAYLIFTB Dual Return Kit (B size extension) B Cabinet modular blowers
BAYLIFTC Dual Return Kit (C size extension) C Cabinet modular blowers
BAYLIFTD Dual Return Kit (D size extension) D Cabinet modular blowers
BAYFLTR206
Filter Access Door Kit (Downflow only) All modular blowers in Downflow orientation
BAYSF1165AA
(a)
1” SlimFit Box with MERV 4 Filter All modular blowers
BAYSF1255BA 1” SlimFit Filter and Insulated Frame All modular blowers when used in side return
application
B Cabinet modular blowers only when in
bottom return application
FLRSF1255 1” Filter replacement (Qty 12) BAYSF1255BA
BAYFLTR203 Horizontal Filter Kit B Cabinet modular blowers in Downflow/
Horizontal
BAYFLTR204 Horizontal Filter Kit C Cabinet modular blowers in Downflow/
Horizontal
BAYFLTR205 Horizontal Filter Kit D Cabinet modular blowers in Downflow/
Horizontal
(a)
Airflow greater than 1600 CFM requires dual returns
