16
P0V0-SVX001-1A-EN
Duct Connections
Table 4. Supply Duct Connections
Upflow Modular Blower with Coil
Note: There are no longer guide holes located on the modular blower
flange.
Modular Blower in Horizontal Left with Coil
Note: There are no longer guide holes located on the modular blower
flange.
Refer to Step 1. Step 2. Step 3. Step 4.
Refer to Step 1. Step 5. Step 3. Step 4.
Modular Blower in Horizontal Right with “A” Coil
Note: Flat or dedicated horizontal coils may require flanges to be bent
upward.
Downflow Modular Blower with Coil
Refer to Step 6. Step 5. Step 7. Step 4. Refer to Step 6. Step 8. Step 4.
GGeenneerraall IInnssttaallllaattiioonn
