Dimensions and Weights
18 RT-SVX46G-EN
Figure 11. Cooling and gas/electric - 3 tons ultra high
efficiency- economizer and barometric relief
damper hood
(a)
Figure 12. Cooling and gas/electric models - 3 tons ultra
high efficiency- swing diameter for hinged
door(s) option
(a)
(a) All dimensions are in inches/millimeters.
Figure 13. Gas/electric models - 3 tons ultra high
efficiency- height of gas pipe required from
inside base of unit to gas shut off assembly
(factory provided) - Y_C models only
6 15/16”
176 MM
9 1/8”
232 MM
17 7/8”
454 MM
16”
406 MM
Applicable to
Y_C models only
22 1/4”
565 MM
4 5/8”
117 MM
Figure 14. Cooling and gas/electric - 4 to 5 tons ultra
high efficiency
(a)
(a) All dimensions are in inches/millimeters.
Figure 15. Cooling and gas/electric - 4 to 5 tons ultra
high efficiency- downflow airflow supply/
return - through-the-base utilities
(a)
(a) All dimensions are in inches/millimeters.
Figure 16. Cooling and gas/electric - 4 to 5 tons ultra
high efficiency- horizontal airflow supply and
return
Note: All dimensions are in inches/millimeters.
Evaporator Section
Access Panel
Alternate Condensate Drain
Connection 3/4 - 14 NPT Dia. Hole
1/2 NPT Gas Connection
(80 Mbh, 120 MBh)
3/4 NPT Gas Connection
(150 Mbh, 200 MBh, 250 MBh)
Control and Compressor
Access Panel
Top Panel
Condenser Fan
Condenser Coil
Unit Control Wire
7/8” (22 MM) Dia. Hole
Service Gauge Port Access
1 3/8” (35 MM) Dia. Hole
Unit Power Wire
1 3/8” (35 MM) Dia. Hole
40 7/8”
1038 MM
4 1/4”
108 MM
27 5/8”
701 MM
88 5/8”
2251 MM
47 7/8”
1216 MM
9 5/8”
244 MM
5 5/8”
143 MM
5 5/8”
143 MM
7 5/8”
194 MM
53 1/4”
1353 MM
4 1/4”
108 MM
18 1/2”
470 MM
4”
102 MM
3 5/8”
92 MM
17 1/2”
444 MM
9 7/8”
251 MM
17 1/2”
444 MM
32 1/8”
816 MM
33”
838 MM
RETURN
SUPPLY
THROUGH THE
BASE CONDENSATE
4 1/8”
104 MM
27 5/8”
701 MM
40 3/4”
1035 MM
4 5/8”
119 MM
THROUGH THE
BASE ELECTRICAL
5 7/8”
149 MM
10 7/8”
276 MM
5”
127 MM
3 3/4”
95 MM
2 3/4”
71 MM
6 1/2”
165 MM
THROUGH THE
BASE GAS
Supply
4 1/4”
108 MM
3/4-14 NPT DIA. HOLE
CONDENSATE DRAIN
27 5/8”
701 MM
4 3/4”
120 MM
32 1/4”
832 MM
16 3/4”
425 MM
23 7/8”
606 MM
19 1/4”
489 MM
9 3/8”
238 MM
3 7/8”
98 MM
Return
