Maintenance
Maintenance requirements for an EarthWise™ purge
system with Tracer® AdaptiView™ control are
described in this section. To ensure efficient and
reliable purge operation, perform all inspections and
procedures at the prescribed intervals. Keep records of
inspection results to establish proper service intervals.
Document changes that occur in purge activity that
could provide information about chiller performance.
WWAARRNNIINNGG
RReeffrriiggeerraanntt uunnddeerr HHiigghh PPrreessssuurree!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss bbeellooww ccoouulldd rreessuulltt iinn
aann eexxpplloossiioonn wwhhiicchh ccoouulldd rreessuulltt iinn ddeeaatthh oorr
sseerriioouuss iinnjjuurryy oorr eeqquuiippmmeenntt ddaammaaggee..
SSyysstteemm ccoonnttaaiinnss ooiill aanndd rreeffrriiggeerraanntt uunnddeerr hhiigghh
pprreessssuurree.. RReeccoovveerr rreeffrriiggeerraanntt ttoo rreelliieevvee pprreessssuurree
bbeeffoorree ooppeenniinngg tthhee ssyysstteemm.. SSeeee uunniitt nnaammeeppllaattee ffoorr
rreeffrriiggeerraanntt ttyyppee.. DDoo nnoott uussee nnoonn--aapppprroovveedd
rreeffrriiggeerraannttss,, rreeffrriiggeerraanntt ssuubbssttiittuutteess,, oorr rreeffrriiggeerraanntt
aaddddiittiivveess..
WWAARRNNIINNGG
HHaazzaarrddoouuss VVoollttaaggee!!
FFaaiilluurree ttoo ddiissccoonnnneecctt ppoowweerr bbeeffoorree sseerrvviicciinngg ccoouulldd
rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy..
DDiissccoonnnneecctt aallll eelleeccttrriicc ppoowweerr,, iinncclluuddiinngg rreemmoottee
ddiissccoonnnneeccttss bbeeffoorree sseerrvviicciinngg.. FFoollllooww pprrooppeerr
lloocckkoouutt//ttaaggoouutt pprroocceedduurreess ttoo eennssuurree tthhee ppoowweerr
ccaann nnoott bbee iinnaaddvveerrtteennttllyy eenneerrggiizzeedd.. VVeerriiffyy tthhaatt nnoo
ppoowweerr iiss pprreesseenntt wwiitthh aa vvoollttmmeetteerr..
WWAARRNNIINNGG
HHoott SSuurrffaaccee!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss bbeellooww ccoouulldd rreessuulltt iinn
sseevveerree bbuurrnnss..
SSuurrffaaccee tteemmppeerraattuurreess mmaayy eexxcceeeedd 330000°°FF ((115500°°CC))..
TToo aavvooiidd ppoossssiibbllee sskkiinn bbuurrnnss,, ssttaayy cclleeaarr ooff tthheessee
ssuurrffaacceess.. IIff ppoossssiibbllee,, aallllooww ssuurrffaacceess ttoo ccooooll bbeeffoorree
sseerrvviicciinngg.. IIff sseerrvviicciinngg iiss nneecceessssaarryy wwhhiillee ssuurrffaaccee
tteemmppeerraattuurreess aarree ssttiillll eelleevvaatteedd,, yyoouu MMUUSSTT ppuutt oonn
aallll PPeerrssoonnaall PPrrootteeccttiivvee EEqquuiippmmeenntt ((PPPPEE))..
Weekly Maintenance
Perform the following maintenance procedure on a
weekly basis:
1. With the purge unit operating, check the purge tank
condensing activity by observing the liquid
refrigerant flow in the moisture-indicating sight
glass located in the liquid drain line immediately
after the filter drier canister. A lack of visible
refrigerant flow in the sight glass indicates one of
the following:
a. A pump-out cycle is necessary.
b. A problem exists with the purge heat transfer
circuit (such as the condensing unit, expansion
device, or purge evaporator coil).
c. A problem exists in the purge control
subsystem.
d. Refrigerant vapor from the chiller condenser is
blocked or restricted.
2. Check the moisture-indicator sight glass. Replace
the filter-drier core if moisture is indicated.
NNoottee:: The need for frequent changes of the filter
drier could be an indication of significant
chiller air or tube leaks.
Semi-Annual Maintenance
Perform the following maintenance procedure on a
semi-annual basis:
1. Inspect the air-cooled condenser coil and clean as
needed. Clean the coil from the fan side using
compressed air or coil cleaner. A dirty coil will
reduce purge efficiency and capacity.
2. Inspect the purge tank and carbon tank insulation
for any damage or degradation. Make any needed
repairs to the insulation.
Annual Maintenance
Perform the following maintenance procedure on an
annual basis:
1. Semi-annual maintenance procedures described in
“Semi-Annual Maintenance,” p. 25.
2. Purge system control checks described in
“Troubleshooting,” p. 28.
3. Open the purge control panel and check all internal
components for such problems as corrosion,
terminal tightness, or signs of overheating.
4. Change the filter-drier assembly.
Replacing the Filter-Drier
Assembly
Following are maintenance instructions for filter-drier
assembly replacement; refer to Figure 2, p. 9, for the
location of this component.
1. At the Tracer® AdaptiView™ display, touch the
SSeettttiinnggss button to display the Settings screen.
Touch the PPuurrggee SSeettttiinnggss button to display the
Purge Settings screen. Touch PPuurrggee MMooddee to
display Purge Mode screen. From this screen, set
the mode to Stop.
2. Isolate the purge unit from the chiller. Close the
isolation valves on the purge vapor inlet and the
liquid return lines.
