Specifications
An EarthWise™ purge system has the specifications
shown in the following table:
Electrical power requirements
115 Vac, 60 Hz, 1-phase, 10.3 A
110 Vac, 50 Hz, 1-phase, 10.3 A
Voltage range is +10%, -15%
Purge compressor motor rated-load ampacity
8 RLA
Total unit ampacity
10.3 A
Minimum circuit ampacity
12.3 A
Carbon tank heater wattage
175 W
Alarm relay output rating 120 Vac, 1/3 hp, 7.2 FLA
Operating temperature range 34°F to 110°F (1.1°C to 43.3°C)
Storage temperature range -40°F to 150°F (-40.0°C to 65.5°C)
Storage and operating humidity range 5% to 95% relative humidity, non-condensing
Mounting Direct-mounted on condenser shell above the liquid level of highest condenser
Dimensions (approximate)
25-3/4 in. (65.4 cm) high x 27-1/2 in. (69.9 cm) wide x 21-3/4 in. (55.2 cm) deep,
with filter-drier
Weight 140 lb (63.5 kg) with filter-drier
Condensing unit refrigerant charge 0.60 lb (0.27 kg) of R-404A
