Customer Wire Selection
Rev. B
Unit Rated Terminal Size Connector Wire Range Disconnect Size Connector Wire Range Circuit Breaker Size Connector Wire Range
Size Voltage (per phase) (per phase) (per phase)
RTAA 70 200/60 760 Amp #4 to 500 MCM 400 Amps Two 3/0 to 500 MCM 400 Amps Two 3/0 to 500 MCM
230/60 310 Amp #8 to 350 MCM 400 Amps Two 3/0 to 500 MCM 350 Amps Two 3/0 to 500 MCM
380/60 310 Amp #8 to 350 MCM 250 Amps #6 to 350 MCM 250 Amps #6 to 350 MCM
460/60 175 Amp #14 to 2/0 250 Amps #6 to 350 MCM 150 Amps #6 to 350 MCM
575/60 175 Amp #14 to 2/0 250 Amps #6 to 350 MCM 125 Amps #6 to 350 MCM
400/50 175 Amp #14 to 2/0 250 Amps #6 to 350 MCM 150 Amps #6 to 350 MCM
RTAA 80 200/60 760 Amp #4 to 500 MCM 400 Amps Two 3/0 to 500 MCM 500 Amps Two 3/0 to 500 MCM
230/60 760 Amp #4 to 500 MCM 400 Amps Two 3/0 to 500 MCM 400 Amps Two 3/0 to 500 MCM
380/60 310 Amp #8 to 350 MCM 250 Amps #6 to 350 MCM 300 Amps #4 to 350 MCM
460/60 175 Amp #14 to 2/0 250 Amps #6 to 350 MCM 175 Amps #6 to 350 MCM
575/60 175 Amp #14 to 2/0 250 Amps #6 to 350 MCM 150 Amps #6 to 350 MCM
400/50 175 Amp #14 to 2/0 250 Amps #6 to 350 MCM 175 Amps #6 to 350 MCM
RTAA 90 200/60 760 Amp #4 to 500 MCM 600 Amps Two 3/0 to 500 MCM 600 Amps Two 3/0 to 500 MCM
230/60 760 Amp #4 to 500 MCM 400 Amps Two 3/0 to 500 MCM 500 Amps Two 3/0 to 500 MCM
380/60 310 Amp* #8 to 350 MCM 400 Amps Two 3/0 to 500 MCM 350 Amps Two 3/0 to 500 MCM
460/60 310 Amp #8 to 350 MCM 250 Amps #6 to 350 MCM 225 Amps #6 to 350 MCM
575/60 175 Amp #14 to 2/0 250 Amps #6 to 350 MCM 175 Amps #6 to 350 MCM
400/50 310 Amp #8 to 350 MCM 250 Amps #6 to 350 MCM 225 Amps #6 to 350 MCM
RTAA 100 200/60 760 Amp #4 to 500 MCM 600 Amps Two 3/0 to 500 MCM 600 Amps Two 3/0 to 500 MCM
230/60 760 Amp #4 to 500 MCM 600 Amps Two 3/0 to 500 MCM 600 Amps Two 3/0 to 500 MCM
380/60 310 Amp* #8 to 350 MCM 400 Amps Two 3/0 to 500 MCM 350 Amps Two 3/0 to 500 MCM
460/60 310 Amp #8 to 350 MCM 250 Amps #6 to 350 MCM 300 Amps Two 3/0 to 500 MCM
575/60 310 Amp #8 to 350 MCM 250 Amps #6 to 350 MCM 200 Amps #6 to 350 MCM
400/50 310 Amp #8 to 350 MCM 250 Amps #6 to 350 MCM 300 Amps Two 3/0 to 500 MCM
RTAA 110 200/60 760 Amp #4 to 500 MCM 600 Amps Two 3/0 to 500 MCM N/A N/A
230/60 760 Amp #4 to 500 MCM 600 Amps Two 3/0 to 500 MCM 600 Amps Two 3/0 to 500 MCM
380/60 310 Amp #8 to 350 MCM 400 Amps Two 3/0 to 500 MCM 400 Amps Two 3/0 to 500 MCM
460/60 310 Amp* #8 to 350 MCM 400 Amps Two 3/0 to 500 MCM 350 Amps Two 3/0 to 500 MCM
575/60 310 Amp #8 to 350 MCM 250 Amps #6 to 350 MCM 225 Amps #6 to 350 MCM
400/50 310 Amp* #8 to 350 MCM 400 Amps Two 3/0 to 500 MCM 350 Amps Two 3/0 to 500 MCM
RTAA 125 200/60 760 Amp #4 to 500 MCM 600 Amps Two 3/0 to 500 MCM N/A N/A
230/60 760 Amp #4 to 500 MCM 600 Amps Two 3/0 to 500 MCM N/A N/A
380/60 310 Amp #8 to 350 MCM 400 Amps Two 3/0 to 500 MCM 450 Amps Two 3/0 to 500 MCM
460/60 310 Amp* #8 to 350 MCM 400 Amps Two 3/0 to 500 MCM 350 Amps Two 3/0 to 500 MCM
575/60 310 Amp #8 to 350 MCM 250 Amps #6 to 350 MCM 250 Amps #6 to 350 MCM
400/50 310 Amp* #8 to 350 MCM 400 Amps Two 3/0 to 500 MCM 350 Amps Two 3/0 to 500 MCM
*760 Amp for X-line #4 to 500 MCM
Wire Selection Size to Main Terminal Block Wire Selection Size to Disconnect Wire Selection Size to Circuit Breaker
Factory Installed Option Factory Installed Option
Power Wire Selection
