RTAA-SVX01A-EN 171
2307-6543
Fuse Description Unit Size Unit Voltage Fuse Type Fuse Size
Rev. B
Condenser Fans All All Class RK5 (600V) 30 Amp
(1F3 - 1F3, 1F7 - 1F9)
Inverter/Auto-transformer All 200/230 No Fuse
(1F18-1F23) Low Ambient Class CC (600V) 6 Amp
Option only
Integrated Pump Package All All Class CC (600V) 20 Amp
(1F24-1F26) Pump Package
Option only
Control Circuit All All Class CC (600V) 10 Amp
(1F15)
Control Power All 200/230 Class CC (600V) 5 Amp
Transformer 380/400 4Amp
(1F16 - 1F17) 460/575 4 Amp
CPM & MCSP All All Buss GMC - 1/4 0.25 Amp 5x20 mm
(1U1F1, 1U4F1, 1U5F1) Littlefuse 239.250
EXV All All Buss GMC - 3/10 0.30 Amp 5x20 mm
(1U3F1) Littlefuse 239.300
CRS All All Buss GMC - 1/10 0.10 Amp 5x20 mm
(1U2F2) Littlefuse 239.200
(1) Do Not Run in Conduct With Higher Voltage Circuits.
5000 FT
2000 FT
1000 FT
Fuse Re
lacement Selection
Control Wire for 30 Volt or Less Circuit
1
Wire size
14 AWG
16 AWG
18 AWG
Maximum Length for Sensor Leads
