58
S9V2-SVX001-1A-EN
Furnace in Horizontal Right with “A” Coil Furnace in Horizontal Right with “A” Coil
Note: Flat or dedicated horizontal coils may require flanges to be bent
upward.
Refer to Step 6, Step 7, Step 8, Step 5
Refer to Step 9, Step 4
Downflow Furnace with Coil Downflow Furnace with Coil
Note: 4GXC* or 4MXC* coils installed on a downflow furnace do not
require a metal drain pan shield or the use of the
MAY*FERCOLKITAA kit.
Refer to Step 10, Step 4
Refer to Step 6, Step 7, Step 8, Step 5
FFuurrnnaaccee GGeenneerraall IInnssttaallllaattiioonn
