Table 14. S9V2B080U4PSBC/D / S9V2B080D4PSBC/D Cooling Airflow
S9V2B080U4PSBC/D / S9V2B080D4PSBC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static
Pressure with Filter
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
2.0 Ton
Cooling 450
CFM/Ton
CFM 892 899 893 872 838
Watts 91 136 180 222 265
Cooling 420
CFM/Ton
CFM 834 841 834 813 777
Watts 77 120 161 202 243
Cooling 400
CFM/Ton
CFM 785 785 781 754 737
Watts 67 106 146 183 229
Cooling 370
CFM/Ton
CFM 738 744 736 714 677
Watts 58 97 134 172 210
Cooling 350
CFM/Ton
CFM 700 705 697 675 638
Watts 52 89 125 161 198
Cooling 330
CFM/Ton
CFM 662 666 658 635 598
Watts 46 81 116 151 187
Cooling 310
CFM/Ton
CFM 624 627 619 596 558
Watts 40 74 107 142 177
Cooling 290
CFM/Ton
CFM 585 588 580 557 518
Watts 35 67 100 133 168
Cooling
2.5 Ton
Cooling 450
CFM/Ton
CFM 1108 1120 1116 1098 1065
Watts 159 213 265 315 365
Cooling 420
CFM/Ton
CFM 1035 1046 1041 1022 989
Watts 133 184 233 281 328
Cooling 400
CFM/Ton
CFM 988 997 992 972 938
Watts 118 167 214 260 306
Cooling 370
CFM/Ton
CFM 916 924 918 897 863
Watts 97 143 188 231 275
Cooling 350
CFM/Ton
CFM 868 875 868 848 813
Watts 85 129 172 213 255
Cooling 330
CFM/Ton
CFM 820 826 819 798 762
Watts 74 116 157 197 237
Cooling 310
CFM/Ton
CFM 772 778 770 749 712
Watts 64 104 143 182 221
Cooling 290
CFM/Ton
CFM 724 729 721 699 663
Watts 56 94 131 168 205
Cooling
3.0 Ton
Cooling 450
CFM/Ton
CFM 1326 1341 1341 1325 1296
Watts 257 320 380 439 497
Cooling 420
CFM/Ton
CFM 1239 1252 1250 1234 1203
Watts 214 273 330 385 440
Cooling 400
CFM/Ton
CFM 1181 1193 1191 1173 1142
Watts 188 245 299 353 405
Cooling 370
CFM/Ton
CFM 1094 1105 1101 1083 1050
Watts 153 207 258 308 358
Cooling 350
CFM/Ton
CFM 1036 1046 1041 1022 989
Watts 133 184 233 281 329
Cooling 330
CFM/Ton
CFM 978 987 982 962 928
Watts 115 164 210 256 302
Cooling 310
CFM/Ton
CFM 920 929 923 902 868
Watts 99 145 189 233 277
Cooling 290
CFM/Ton
CFM 863 870 863 843 807
Watts 84 128 170 212 253
Cooling
3.5 Ton
Cooling 450
CFM/Ton
CFM 1547 1565 1568 1556 1529
Watts 392 463 531 598 664
Cooling 420
CFM/Ton
CFM 1443 1460 1462 1448 1420
Watts 324 391 456 519 581
Cooling 400
CFM/Ton
CFM 1375 1391 1391 1376 1347
Watts 284 348 410 471 530
Cooling 370
CFM/Ton
CFM 1273 1287 1286 1269 1239
Watts 230 290 349 405 461
Cooling 350
CFM/Ton
CFM 1205 1218 1215 1199 1167
Watts 198 256 312 366 420
Cooling 330
CFM/Ton
CFM 1137 1149 1146 1128 1096
Watts 170 225 278 330 381
Cooling 310
CFM/Ton
CFM 1069 1080 1076 1057 1024
Watts 145 197 248 297 345
Cooling 290
CFM/Ton
CFM 1002 1012 1007 987 954
Watts 122 172 220 266 313
